Description

The GE IC660TBD024K is an enhanced and robust communication gateway module from the GE Fanuc Genius® I/O system, specifically designed as a Genius Bus to TCP/IP Ethernet Interface. This module serves as a critical bidirectional protocol converter, facilitating seamless and high-fidelity data exchange between the deterministic Genius bus network and standard IEEE 802.3 Ethernet networks. The core function of the GE IC660TBD024K is to map data from up to 32 Genius I/O devices—including discrete, analog, and special function blocks—into standard Ethernet TCP/IP protocols. This allows any Ethernet-enabled host system, such as a PLC, HMI, SCADA system, or enterprise-level software, to directly access, monitor, and control Genius I/O points without requiring a native Genius bus controller in the main rack. The “K” suffix in the model number typically indicates a specific hardware revision or an enhanced feature set, such as improved processing power, expanded memory, or support for additional protocols compared to the base IC660TBD024 model. Engineered for uncompromising industrial reliability, the GE IC660TBD024K provides electrical isolation and advanced diagnostics, making it an indispensable tool for modernizing legacy systems, integrating disparate automation islands, and implementing comprehensive Industrial Internet of Things (IIoT) connectivity strategies.

IC660TBD024K GE

Technical Specifications

Main Features and Advantages

Comprehensive Protocol Support and Connectivity: The GE IC660TBD024K provides versatile connectivity options. It supports native GE SRTP protocol for efficient data exchange with GE HMIs and software, and it also functions as a Modbus TCP Server. This Modbus TCP capability is a significant advantage, as it allows virtually any modern PLC, HMI, SCADA system, or data analytics platform that supports the ubiquitous Modbus protocol to read from and write to the Genius I/O blocks, enabling unparalleled integration flexibility with third-party systems.

Advanced Embedded Web Server for Intuitive Management: A standout feature of the GE IC660TBD024K is its integrated web server. Users can access the module’s configuration and diagnostic pages using any standard web browser, providing a user-friendly interface for setting the IP address, configuring the Genius bus scanlist, defining data points, and monitoring real-time I/O values. This web interface offers detailed diagnostic information on both the Genius network and Ethernet connection health, simplifying commissioning and reducing mean time to repair (MTTR) through remote troubleshooting.

High-Density Data Gateway and Network Optimization: By consolidating data from up to 32 Genius devices into a single Ethernet connection, the GE IC660TBD024K dramatically optimizes network architecture. It reduces the need for multiple gateways or controllers, simplifies wiring, and centralizes data access. This makes it an ideal solution for aggregating data from remote panels or legacy machines and bringing it onto a modern plant-wide Ethernet network for centralized monitoring and control.

Ruggedized Design for Industrial Environments: Designed for reliability on the factory floor, the module includes 1500V of isolation between the Genius bus and the Ethernet network. This protects sensitive network equipment from voltage transients, ground loops, and electrical noise commonly found in industrial settings. Its robust design ensures stable operation in environments with high electromagnetic interference (EMI), providing dependable data integrity for critical control and monitoring applications.

Application Field

The GE IC660TBD024K is deployed across a wide spectrum of industrial automation applications where integrating legacy Genius I/O into modern Ethernet-based architectures is required. It is extensively used for enterprise data connectivity, allowing SCADA systems and plant asset management software to collect real-time data from Genius-based remote I/O panels for operational monitoring and historical trending. In modernization projects, it enables facilities to retain their investment in reliable Genius I/O wiring and devices while upgrading their central control platform to newer Ethernet-native PLCs from various manufacturers. The GE IC660TBD024K is also ideal for providing HMIs with a direct window into machine state data and for enabling IIoT platforms to access machine data for predictive maintenance and overall equipment effectiveness (OEE) calculations without requiring controller intervention.

IC660TBD024K GE

Related Products

GE IC660TBD024: The standard version of this Ethernet gateway, upon which the “K” variant is based.

GE IC660TBD025: A Genius to EtherNet/IP gateway, designed for native integration with Allen-Bradley ControlLogix/CompactLogix systems.

GE Genius I/O Blocks (e.g., IC660ELB921, IC660EJD920): The discrete and analog I/O blocks that are connected to the Genius bus.

GE IC690TBD202: A Genius to Ethernet gateway designed for the Series 90-30 platform.

ProSoft Technology MVI56-GEC: A competing Genius to Ethernet gateway module for ControlLogix racks.

Managed Ethernet Switches: Industrial-grade switches used to build the network infrastructure connecting the IC660TBD024K.
