Description

The GE IC695CRU320 is a high-performance Central Processing Unit (CPU) for the RX3i series, a core member of GE’s (now part of Emerson) versatile PACSystems family of Programmable Automation Controllers (PACs). This module serves as the intelligent core and computational engine of the control system, responsible for executing the user’s control logic, managing data, and coordinating communication across the entire backplane and networked devices. The GE IC695CRU320 is specifically engineered to handle complex, data-intensive, and high-speed automation tasks that are beyond the capability of standard PLCs. With a 20 MHz processor and a substantial 32 MB of user memory, it provides the necessary horsepower for advanced applications involving extensive program code, complex data structures, and sophisticated motion control or process control algorithms.

As the cornerstone of an RX3i rack, the GE IC695CRU320 offers a powerful migration path for users of older GE Fanuc Series 90-30 systems, often allowing for a direct hardware upgrade with minimal software changes. It supports a vast library of IEC 61131-3 programming languages, including Ladder Logic, Structured Text, and Function Block Diagram, within the Proficy Machine Edition software environment. The controller is designed for robust and reliable operation in demanding industrial environments, featuring robust diagnostics, a removable memory cartridge for program backup, and support for a wide range of high-speed I/O and communication modules. Implementing the GE IC695CRU320 ensures a scalable, powerful, and future-proof platform for the most challenging control applications.

GE IC695CRU320

Technical Specifications

Main Features and Advantages

The GE IC695CRU320 delivers a compelling set of features centered around performance, connectivity, and rugged reliability. Its 20 MHz processor and 32 MB memory provide a significant performance headroom for executing large control programs with fast scan times, which is critical for high-speed machinery and complex sequential processes. A key advantage is its seamless integration within the PACSystems ecosystem; it can exchange data with other RX3i and RX7i controllers over a Global Data network, enabling powerful multi-CPU architectures for distributed control.

The module includes a versatile serial port that supports multiple protocols, allowing for easy connection to HMIs, drives, and other serial devices without requiring an additional communication module. For program security and transfer, the removable Type 2 memory cartridge is invaluable, allowing for quick controller replacement and program restoration, which drastically reduces system recovery time during maintenance or failures. The GE IC695CRU320 is also built to withstand the rigors of the factory floor, with components rated for industrial temperature ranges and high immunity to electrical noise and vibration. This combination of raw power, flexible connectivity, and industrial toughness makes the GE IC695CRU320 a highly reliable and capable choice for a central controller.

Application Field

The GE IC695CRU320 is deployed in a wide array of industries that require a robust and powerful control platform. In complex machine automation, such as automotive assembly lines, packaging machinery, and material handling systems, its fast processing speed is essential for coordinating robots, vision systems, and high-speed indexing conveyors. For process control applications in industries like water/wastewater, chemical, and pharmaceutical, the large memory capacity of the GE IC695CRU320 handles the extensive recipe management, data logging, and PID loop control required for batch and continuous processes.

The infrastructure sector utilizes this CPU for controlling energy management systems, turbine control, and large-scale HVAC systems in airports and commercial buildings. Its ability to handle complex networking and data-intensive tasks also makes it suitable for SCADA systems where it acts as a master station, collecting data from remote sites. Essentially, any application that has outgrown the capabilities of a mid-range PLC or requires a scalable, high-performance platform for future expansion will find an ideal solution in the GE IC695CRU320 RX3i CPU.

GE IC695CRU320

Related Products

GE IC695PSD140: A 120/240V AC power supply module, commonly used to provide power to the RX3i rack hosting the IC695CRU320.

GE IC695CHS012: A 12-slot RX3i universal backplane, providing the physical foundation for the IC695CRU320 and its I/O modules.

GE IC694MDL754: A high-density 32-point discrete output module, representing the type of I/O the IC695CRU320 can manage.

GE IC695ETM001: A dual-port Ethernet interface module, which can be used alongside the IC695CRU320 for additional network connectivity and high-speed EGD data exchange.

GE IC695ALG600: An analog input module, suitable for systems where the IC695CRU320 processes numerous analog signals.

GE IC693CPU350: A Series 90-30 CPU, representing the legacy platform for which the IC695CRU320 is a common and powerful upgrade path.
