SMC AN30-03 Pneumatic Silencer R3/8 Resin Body 30dB Noise Reduction In Stock

Brand new and in stock (库存现货 / SMC现货) - ready to ship within 3-5 days.

The AN30-03 is the size-30 model of the SMC AN series of compact resin silencers. It screws directly onto the exhaust port of solenoid valves, cylinders or valve manifolds and cuts exhaust noise by about 30 dB(A) using a sintered-resin sound-absorbing element. With no moving parts, a large 60 mm² effective area (low back-pressure) and a recommended flow of up to 5.0 m³/min (ANR), it is the economical standard choice for exhaust silencing on 3/8 ports.

Details:

• Model: AN30-03 | Series: AN compact resin silencer

• Connection: R 3/8 male thread | body Ø 20 x 58.5 mm, hex 17 mm

• Noise reduction: 30 dB(A) | effective area 60 mm² | sonic conductance 12 dm³/(s·bar)

• Recommended flow: 5.0 m³/min (ANR) or less | max operating pressure 1.0 MPa

• Fluid: compressed air | ambient/fluid temperature 5...60 °C | weight 5.5 g

• Brand: SMC (Japan) | Condition: Brand New, Original | Stock: 库存现货, in stock

Lead Time: IN STOCK, 3-5 days after payment
Delivery: FedEx, SF Express, EMS
Condition: In Stock, Brand New
Payment Method: T/T, 30% deposit, 70% balance of payment
Price: Please contact us for further inquiry. All quotes are based on EXW excluding tax.
Remark: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
