The Kontron 18008-0000-10-1 is a high-reliability 250W power supply module designed for 6U CompactPCI (CPCI) systems operating under the PICMG 2.11 standard. Developed by Kontron—a global leader in embedded computing and industrial-grade electronics—the Kontron 18008-0000-10-1 delivers stable, regulated DC power to backplane-based modular systems commonly deployed in telecommunications infrastructure, defense electronics, transportation control, and industrial automation. Its primary outputs focus on the critical +5V and +3.3V rails required by legacy and mixed-generation CPCI CPU and I/O boards, ensuring seamless compatibility across heterogeneous chassis configurations.
As a full-size 6U × 4HP (single-slot) module, the Kontron 18008-0000-10-1 integrates directly into standard CPCI backplanes without requiring auxiliary cabling, leveraging the J1/J2 connectors for both power input and system signaling. The unit supports wide-range AC or DC input options (depending on variant), includes comprehensive protection circuitry, and is engineered for conduction-cooled or forced-air environments—making it suitable for sealed or fanless enclosures in extreme conditions. With an MTBF exceeding 200,000 hours and compliance with stringent industrial EMC and safety standards, the Kontron 18008-0000-10-1 serves as a dependable power backbone in systems where uptime and resilience are non-negotiable.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 18008-0000-10-1 |
| Manufacturer | Kontron AG |
| Product Type | 6U CompactPCI power supply module (PICMG 2.11 compliant) |
| Total Output Power | 250 W continuous |
| Primary Outputs | +5V @ up to 30A, +3.3V @ up to 20A |
| Auxiliary Outputs | ±12V (typically for management or I/O signaling) |
| Input Voltage Range | 90–264 VAC (universal) or 48 VDC (variant-dependent) |
| Efficiency | Up to 85% (typical at 50% load) |
| Cooling Method | Conduction-cooled (baseplate) or forced air (with optional heatsink) |
| Operating Temperature | 0°C to +70°C (conduction-cooled); extended ranges available |
| Form Factor | 6U CompactPCI (233.35 mm × 160 mm × 20.32 mm / 4HP) |
| Protections | Overvoltage (OVP), overcurrent (OCP), short-circuit, thermal shutdown |
| Certifications | CE, FCC, RoHS, UL/cUL; meets EN 50155 (railway) and MIL-STD-810 (optional) |
Main Features and Advantages
Robust power delivery for legacy and hybrid CPCI systems: The Kontron 18008-0000-10-1 is specifically optimized for systems that rely heavily on +5V and +3.3V logic—common in older but still operational industrial and military platforms. By prioritizing these rails with high-current capability (30A on +5V), it eliminates the need for inefficient DC-DC converters on downstream boards, reducing heat and improving overall system efficiency. This makes the Kontron 18008-0000-10-1 an ideal choice for life-extension projects or spare-part stocking in aging infrastructure.
Engineered for extreme reliability and serviceability: Built with industrial-grade components and featuring full digital supervision via the PICMG 2.11 IPMI-like interface, the Kontron 18008-0000-10-1 supports hot-swap in compatible chassis—allowing power module replacement without system shutdown. Its conduction-cooled design transfers heat directly through the card edge to the chassis frame, enabling operation in dust-laden, high-vibration, or vacuum-sealed environments where fans would fail. The inclusion of remote sense lines ensures precise voltage regulation at the load, even over long backplane traces.
Comprehensive protection and global deployment readiness: The Kontron 18008-0000-10-1 incorporates multi-layered safeguards—including OVP, OCP, and thermal foldback—that prevent cascading failures during electrical faults. It meets international safety and EMC standards out of the box, and optional conformal coating or ruggedization extends its use into railway (EN 50155), defense (MIL-STD-810G), and offshore applications. Whether deployed in a telecom central office or an armored vehicle, the Kontron 18008-0000-10-1 delivers consistent, clean power under the most demanding conditions.
Application Field
The Kontron 18008-0000-10-1 is extensively used in mission-critical embedded systems where long lifecycle support and environmental resilience are paramount. In telecommunications, it powers legacy CompactPCI-based DSLAMs, media gateways, and signal processing blades in central offices that remain in service due to high upgrade costs. Its ability to operate from universal AC input simplifies global deployment, while conduction cooling ensures silent, maintenance-free operation in sealed racks.
Within defense and aerospace, the Kontron 18008-0000-10-1 is integrated into radar data processors, avionics test benches, and naval command systems—often in conduction-cooled chassis that meet MIL-STD-810 shock/vibe requirements. The module’s high MTBF and robust protections align with DO-160 or MIL-STD-704 power quality expectations, making it suitable for airborne or shipboard use when properly qualified.
In railway signaling and rolling stock, the Kontron 18008-0000-10-1 complies with EN 50155 for temperature, humidity, and surge immunity, powering train control units and passenger information systems. Similarly, in energy and industrial automation, it supports SCADA front-end processors and substation RTUs housed in outdoor cabinets subject to wide temperature swings. Across all these sectors, the Kontron 18008-0000-10-1 provides a proven, field-tested power solution that bridges the gap between legacy architecture demands and modern reliability expectations.
Related Products
18008-0000-20-1: Higher-power (300W) variant with enhanced +12V output for mixed-voltage systems
18008-0000-01-1: Early revision with slightly different input filtering; functionally similar
18108-0000-10-1: Dual-redundant power supply module (2+1 configuration) based on same platform
CP6001: Kontron 6U CompactPCI single-board computer often powered by 18008-0000-10-1
PS-MC250: Alternative 250W CPCI PSU from Schroff/Elma, pin-compatible but different firmware
PICMG 2.11 Backplane: Standard 6U backplane required to host 18008-0000-10-1 with power management
KTFC-6U-FAN: Kontron forced-air cooling frame for systems using 18008-0000-10-1 in non-conduction setups
Installation and Maintenance
Pre-installation preparation: Before inserting the Kontron 18008-0000-10-1, verify that the CompactPCI backplane complies with PICMG 2.11 and provides adequate mechanical retention. Ensure the system chassis supports the thermal dissipation method—conduction-cooled versions require direct metal-to-metal contact with a cooled card guide or baseplate. Confirm input power source matches the module label (AC or DC). Ground the chassis properly to avoid ESD damage during handling. If hot-swap is enabled, ensure the system controller recognizes the Kontron 18008-0000-10-1’s presence via the IPMB bus before applying main power.
Maintenance recommendations: The Kontron 18008-0000-10-1 is designed for maintenance-free operation but should be visually inspected periodically for signs of overheating, corrosion, or connector wear—especially in high-humidity or corrosive atmospheres. In conduction-cooled installations, ensure thermal interface material (if used) remains intact and free of gaps. Avoid frequent hot-swap cycles beyond rated specifications to preserve connector life. Monitor system event logs for power faults or warnings related to the Kontron 18008-0000-10-1, which may indicate upstream power quality issues. Store spare units in anti-static packaging at room temperature with low humidity to preserve component integrity.
