The combination of ABB 3BHB003230R0101, ABB 3BHL000392P0101, and ABB 5SHX1060H0001 represents a foundational building block for scalable, reliable control within ABB’s AC 800M distributed control system (DCS), widely deployed in power generation, water treatment, oil & gas, and heavy industry. The ABB 3BHB003230R0101 is a terminal base unit designed to securely mount and electrically interface I/O modules like the ABB 3BHL000392P0101—a 16-channel digital input (DI) module that captures field signals from switches, relays, and proximity sensors. Together, they form a robust signal acquisition node. Powering this subsystem is the ABB 5SHX1060H0001, a high-efficiency 24 VDC/10 A industrial power supply engineered for continuous operation in demanding environments.
This trio integrates seamlessly into System 800xA, ABB’s unified automation platform, enabling centralized engineering, diagnostics, and asset management. The ABB 3BHL000392P0101 supports voltage-free or powered digital inputs (24 VDC nominal), with galvanic isolation between field and system sides to prevent ground loops and enhance noise immunity. Mounted on the ABB 3BHB003230R0101 base, it benefits from secure screw terminals, LED status per channel, and hot-swap capability when used in redundant racks. Meanwhile, the ABB 5SHX1060H0001 delivers stable, regulated power with overvoltage, short-circuit, and thermal protection—ensuring uninterrupted operation even during grid disturbances. Together, these three components deliver a turnkey solution for expanding or maintaining critical control infrastructure with OEM-grade reliability.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 3BHB003230R0101 (Base), 3BHL000392P0101 (DI Module), 5SHX1060H0001 (Power Supply) |
| Manufacturer | ABB |
| Product Type | Terminal Base + Digital Input Module + DIN-Rail Power Supply |
| I/O Type | 16-channel Digital Input (Sink/Source, 24 VDC) |
| Input Voltage Range | 15–30 VDC (nominal 24 VDC) |
| Isolation | 500 Vrms between field and backplane |
| Power Supply Output | 24 VDC / 10 A (240 W) |
| Input Voltage (PSU) | 85–264 VAC, 47–63 Hz or 120–370 VDC |
| Mounting | DIN rail (35 mm, EN 60715 compliant) |
| Operating Temperature | –25°C to +70°C (PSU derating above 60°C) |
| Status Indication | Per-channel LEDs on 3BHL000392P0101; DC OK / Fault on 5SHX1060H0001 |
| Certifications | CE, UL 61010-1, cUL, CSA, RoHS |
| Dimensions (W×H×D) | Base: 45×125×100 mm; DI Module: 30×125×100 mm; PSU: 70×125×120 mm |
Main Features and Advantages
Modular, future-proof I/O architecture: The ABB 3BHB003230R0101 terminal base provides mechanical stability and electrical connectivity for the ABB 3BHL000392P0101 digital input module, enabling rapid replacement without rewiring. This modular design reduces maintenance time and supports phased system upgrades. Each input channel on the ABB 3BHL000392P0101 features individual LED indicators for real-time status visibility—critical during troubleshooting in complex plants.
Industrial-grade power integrity: The ABB 5SHX1060H0001 is not just a power supply—it’s a resilience enabler. With >88% efficiency, convection cooling (no fan), and MTBF exceeding 500,000 hours, it ensures clean, stable 24 VDC delivery to the I/O chain. Its wide input range accommodates global voltage standards, while built-in protections safeguard both the PSU and downstream electronics like the ABB 3BHL000392P0101 from surge events or wiring faults.
Seamless System 800xA integration: All three components are natively supported in ABB’s engineering tools (Control Builder M, Asset Optimization). Configuration data flows automatically from design to runtime, minimizing human error. The ABB 3BHL000392P0101 supports diagnostic messaging (e.g., wire break detection), which appears directly in operator alarms—enhancing situational awareness. When powered by the ABB 5SHX1060H0001 and mounted on the ABB 3BHB003230R0101, this subsystem meets the stringent availability requirements of SIL 2 applications when deployed in redundant topologies.
Application Field
This ABB component trio is extensively used in industries where signal reliability and system uptime are non-negotiable. In thermal and hydroelectric power plants, the ABB 3BHL000392P0101 monitors breaker status, pump running signals, and valve limit switches, with data fed into turbine or boiler protection logic executed on AC 800M controllers. The ABB 3BHB003230R0101 base ensures secure termination in high-vibration switchgear rooms, while the ABB 5SHX1060H0001 maintains power during brownouts common in remote grid locations.
In municipal water and wastewater facilities, the same setup acquires dry-run alarms from pumps, high-level tank signals, and chemical dosing valve feedback—enabling automated response to prevent overflow or equipment damage. Within oil & gas terminals, the ABB 3BHL000392P0101 interfaces with ESD pushbuttons, fire panel contacts, and compressor trip signals, forming part of a certified safety instrumented function (SIF). Even in mining conveyor systems and cement kilns, this combination delivers dependable digital sensing under dust, heat, and electrical noise. Wherever ABB AC 800M forms the control backbone, the ABB 3BHB003230R0101, ABB 3BHL000392P0101, and ABB 5SHX1060H0001 work in concert to ensure process visibility and operational continuity.
Related Products
3BHB003231R0101: 24-channel terminal base compatible with wider I/O modules
3BHL000393P0101: 16-channel digital output (DO) module for relay/solenoid control
5SHX1060H0002: 24 VDC / 5 A variant of the 5SHX1060H0001 power supply
TB510: Compact terminal base for space-constrained panels
CI854A: AC 800M communication module for PROFIBUS DP integration
PM864: AC 800M CPU controller that hosts I/O like 3BHL000392P0101
5SHX1440H0001: 48 VDC power supply for specialized applications
3BSE022500R1: Redundant power supply base for dual 5SHX1060H0001 units
