The PROSOFT RLX2-IHNF is a rugged, industrial-grade wireless Ethernet radio designed to deliver reliable, secure, and high-performance Wi-Fi connectivity in demanding automation environments. Part of ProSoft Technology’s RLX2 Wireless Family, the RLX2-IHNF supports dual-band operation (2.4 GHz and 5 GHz) under IEEE 802.11a/b/g/n standards, enabling flexible deployment in congested RF environments. With an IP67-rated stainless steel housing, wide operating temperature range (–40°C to +75°C), and certifications for Class I Division 2, ATEX Zone 2, and IEC 61850-3, it is engineered for use in oil & gas, mining, water treatment, and heavy manufacturing.
Functioning as a wireless client, access point, or bridge, the PROSOFT RLX2-IHNF seamlessly integrates with major control platforms—including Rockwell Automation (Allen-Bradley), Siemens, Schneider Electric, and ABB—to wirelessly connect PLCs, HMIs, remote I/O racks, motor drives, and mobile assets like AGVs or cranes. It supports critical industrial protocols such as EtherNet/IP, Modbus TCP, PROFINET, and DHCP/Ping-based diagnostics without requiring tunneling or proprietary gateways. Advanced features like fast roaming (<50>, VLAN tagging, QoS prioritization, and WPA2/WPA3 encryption ensure deterministic performance and cybersecurity compliance in OT networks.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | PROSOFT RLX2-IHNF |
| Manufacturer | ProSoft Technology (a Rockwell Automation company) |
| Wireless Standard | IEEE 802.11a/b/g/n |
| Frequency Bands | 2.4 GHz (2400–2483.5 MHz), 5 GHz (5150–5850 MHz, region-dependent) |
| Data Rate | Up to 150 Mbps (per band) |
| Antenna | External RP-SMA connectors (antennas sold separately) |
| Ethernet Ports | 1 x 10/100 Mbps copper (RJ45), auto-MDIX |
| Power Input | 12–48 VDC (nominal), 24 VDC typical |
| Operating Temperature | –40°C to +75°C (–40°F to +167°F) |
| Enclosure Rating | IP67, NEMA 6P |
| Certifications | Class I Div 2 (Groups A, B, C, D), ATEX Zone 2, CE, FCC, IEC 61850-3, IEC 61000-6-2/4 |
| Mounting | DIN rail (TS-35) or panel mount |
| Security | WPA2-PSK/AES, WPA3-SAE, MAC filtering, RADIUS (via external server) |
| Management | Web GUI, ProSoft Configuration Builder (PCB), SNMP v1/v2c |
Main Features and Advantages
✅ True Industrial Durability: IP67 stainless steel enclosure withstands washdowns, dust, salt spray, and extreme temperatures—ideal for outdoor or hazardous locations.
✅ Seamless Protocol Transparency: Passes EtherNet/IP, Modbus TCP, and PROFINET traffic natively—no protocol conversion or data mapping required.
✅ Fast Roaming (<50>: Enables uninterrupted communication for mobile applications like AGVs, overhead cranes, or rail-guided vehicles.
✅ Dual-Band Flexibility: Operate on less-congested 5 GHz band for high-speed links or 2.4 GHz for longer range—select per site survey.
✅ Cybersecurity Ready: Supports modern WPA3, VLAN segmentation, and port-based ACLs to meet IEC 62443 and NIST SP 800-82 guidelines.
✅ Easy Configuration & Diagnostics: Use intuitive ProSoft Configuration Builder (PCB) software or built-in web interface for setup, monitoring, and firmware updates.
Application Field
The PROSOFT RLX2-IHNF is widely deployed wherever wired Ethernet is impractical, costly, or impossible:
Oil & Gas: Connect remote wellhead controllers, tank farm level sensors, and pipeline monitoring stations in Class I Div 2 areas.
Water/Wastewater: Link pump stations, lift stations, and SCADA RTUs across large municipal networks without trenching fiber.
Factory Automation: Enable wireless HMIs on moving machinery, robotic cells, or rotating tables where drag chains fail.
Material Handling: Provide continuous communication to AGVs, automated forklifts, and conveyor systems with fast roaming.
Mining & Metals: Deploy in dusty, vibrating environments to monitor crushers, conveyors, and stackers with IP67 reliability.
Renewables: Connect solar tracker controllers or wind turbine condition monitoring systems in remote fields.
Related Products
PROSOFT RLX2-IHWBP: Same radio with integrated broadband power supply and PoE output.
PROSOFT RLX2-IHWIF: Fiber-optic version for ultra-long-distance or EMI-immune links.
PROSOFT MVI56-MCM: Modbus serial module for Allen-Bradley ControlLogix (often paired with RLX2 for legacy device integration).
PROSOFT AN-X2-AB-DHRIO: Gateway for DH+/RIO to EtherNet/IP—complements wireless I/O strategies.
CISCO IW6300: Enterprise-grade alternative, but lacks native industrial certifications and protocol transparency.
Phoenix Contact FL WLAN: Competitor with similar specs, but ProSoft offers deeper Rockwell integration.
Installation and Maintenance
? Best Practices for Deployment:
Conduct a site survey using tools like Ekahau or NetScout to select optimal channel and band (avoid co-channel interference).
Use high-gain directional antennas for point-to-point links; omnidirectional for coverage zones.
Ensure antennas are rated for the environment (e.g., IP68, lightning protection).
Power via isolated 24 VDC supply with surge suppression (built-in TVS diodes provide secondary protection).
Enable VLANs to segment control traffic from IT or guest networks.
? Maintenance & Troubleshooting:
Monitor RSSI (Received Signal Strength) and retransmission rate via PCB—values below –75 dBm or >5% retransmissions indicate link issues.
Update firmware annually via web UI to patch security vulnerabilities.
Clean antenna connectors periodically in corrosive atmospheres.
Use ping watchdog or CIP connection health in PLC logic to trigger alarms on wireless dropout.
