LAM 810-810193-003 Plasma Chamber Assembly – Genuine OEM Part for 2300® Flex Dielectric Etch Systems

The LAM 810-810193-003 is an original equipment manufacturer (OEM) upper electrode assembly designed specifically for use in Lam Research’s 2300® Flex series of dielectric etch systems, particularly those configured for silicon dioxide (SiO₂) and silicon nitride (Si₃N₄) plasma etching.

Manufacturer:
Our extensive catalogue, is available now for dispatch to the worldwide.
  • Email: sales@slxytech.com
  • WhatsApp / Wechat:8617062388866
  • Phone:+86 17062388866

Description

The LAM 810-810193-003 is an original equipment manufacturer (OEM) upper electrode assembly designed specifically for use in Lam Research’s 2300® Flex series of dielectric etch systems, particularly those configured for silicon dioxide (SiO₂) and silicon nitride (Si₃N₄) plasma etching. As a core plasma-facing component within the reaction chamber, the LAM 810-810193-003 plays a pivotal role in establishing the electric field geometry that governs ion density, directionality, and uniformity across the 300mm wafer surface. Constructed from high-purity aluminum with specialized ceramic or yttrium oxide coatings, this electrode resists chemical erosion from aggressive fluorocarbon plasmas while minimizing metallic contamination and particle shedding—critical factors in sub-40nm semiconductor manufacturing.

Integrated into the Exelan® dielectric etch module of the 2300 Flex platform, the LAM 810-810193-003 works in concert with the lower cathode and RF matching network to enable precise control over critical dimension (CD) bias, etch rate stability, and profile fidelity. Its design incorporates precision-machined gas distribution channels and thermal management features to ensure consistent process performance over extended campaigns. The LAM 810-810193-003 is not merely a mechanical part but a functional enabler of advanced etch processes such as shallow trench isolation (STI), interlayer dielectric (ILD), and contact/via formation in both logic and memory device fabrication.

Technical Specifications

Parameter NameParameter Value
Product Model810-810193-003
ManufacturerLam Research Corporation
Product TypeUpper Electrode Assembly (Plasma Chamber Component)
Compatible Tool PlatformLam 2300® Flex (Exelan® Dielectric Etch Module)
Wafer Size Support300 mm
Electrode MaterialHigh-purity aluminum with ceramic/yttrium oxide coating
RF Connection TypeStandard coaxial feedthrough (tool-specific interface)
Operating Plasma GasesC₄F₈, CF₄, CHF₃, Ar, O₂, and other fluorocarbon-based chemistries
Temperature ToleranceUp to 150°C continuous (with active cooling via tool’s thermal system)
Surface FinishMirror-polished, Ra < 0>
CertificationsFull OEM traceability, RoHS compliant, SEMI S2/S8 compatible
Dimensions (Approx.)Ø380 mm × 45 mm (varies slightly by revision)

Main Features and Advantages

Precision plasma field shaping: The LAM 810-810193-003 features a meticulously engineered electrode face with optimized contouring and gas injection ports that create a highly uniform plasma sheath across the entire wafer. This geometric precision directly translates to improved etch rate uniformity (<±2%) and minimized center-fast or edge-fast profiles—essential for high-yield production of advanced nodes.

Advanced erosion-resistant coating: Unlike generic replacements, the LAM 810-810193-003 utilizes Lam’s proprietary ceramic or yttrium-based coating technology that dramatically extends component life in aggressive fluorine-rich plasmas. This reduces metal contamination (Al, Fe, Ni) to parts-per-trillion levels, preventing device killer defects and enabling longer chamber clean intervals.

Seamless integration and process repeatability: As a genuine Lam OEM part, the LAM 810-810193-003 is manufactured to exacting tolerances and undergoes full electrical and dimensional validation. When installed, it requires no requalification of existing etch recipes—ensuring immediate return to baseline performance after maintenance. This eliminates costly engineering lots and accelerates tool recovery post-PM.

Particle control through surface engineering: The mirror-finish surface and low-outgassing materials of the LAM 810-810193-003 minimize nucleation sites for polymer buildup, reducing flaking during plasma ignition or pressure transitions. In high-volume fabs, this directly correlates to lower defect density and higher yield in sensitive backend-of-line (BEOL) layers.

Application Field

The LAM 810-810193-003 is deployed exclusively in semiconductor wafer fabrication facilities utilizing Lam Research’s 2300 Flex platform for dielectric etch applications. It is a mission-critical component in the production of DRAM, NAND flash, and advanced logic devices (e.g., 5nm/3nm FinFETs), where nanometer-scale etch accuracy determines device performance and reliability. Specifically, the LAM 810-810193-003 is used in shallow trench isolation (STI) modules to define active areas with vertical sidewalls and minimal footing, as well as in interlayer dielectric (ILD) etch steps that form the insulating layers between metal interconnects.

In 3D NAND manufacturing, the LAM 810-810193-003 enables high-aspect-ratio contact (HARC) etching through dozens of alternating oxide/nitride stacks—demanding extreme profile control and minimal bowing over depths exceeding 50:1. Similarly, in advanced CMOS image sensors and power devices, its stable plasma characteristics support deep SiO₂ trench etches with smooth sidewalls and consistent critical dimensions. Any deviation in electrode condition—such as coating wear, surface roughening, or micro-cracking—can induce microloading effects or CD drift, directly impacting bit error rates or leakage currents. Therefore, timely replacement with a genuine LAM 810-810193-003 is not just maintenance—it’s a yield safeguard.

Related Products

  • 810-810194-003: Lower electrode (cathode) assembly—complements 810-810193-003 in the same chamber

  • 810-810201-005: Focus ring kit—works with 810-810193-003 to maintain edge uniformity

  • 810-810188-002: Chamber liner assembly—protects walls from plasma erosion during 810-810193-003 operation

  • 810-810196-001: Gas distribution plate—integrated upstream of 810-810193-003 for precursor delivery

  • 810-810190-004: RF feedthrough insulator—ensures signal integrity to 810-810193-003

  • 810-810210-007: Thermocouple assembly—monitors temperature near 810-810193-003 during etch

  • 810-810199-006: Shield kit—reduces deposition on non-plasma-facing surfaces around 810-810193-003

Installation and Maintenance

Pre-installation preparation: Before installing the LAM 810-810193-003, ensure the 2300 Flex chamber has been fully vented, purged, and grounded. Inspect the RF feedthrough and sealing surfaces for damage or residue. Clean all mating surfaces with semiconductor-grade IPA and lint-free wipes. Verify that the new LAM 810-810193-003 matches the revision level specified in your tool’s bill of materials—older or newer revisions may affect plasma tuning. Handle the electrode only with powder-free gloves to prevent skin oils from compromising coating adhesion or introducing sodium contamination.

Maintenance recommendations: Monitor electrode condition via routine optical emission spectroscopy (OES) and etch rate tracking. Replace the LAM 810-810193-003 when coating thickness loss exceeds 20% (typically after 5,000–8,000 wafers, depending on chemistry). After installation, perform a standard chamber seasoning run followed by a baseline etch qualification lot. Never attempt to recoat or refurbish the LAM 810-810193-003 in-house—non-OEM rework voids process warranties and risks catastrophic particle events. Store unused units in nitrogen-purged containers to prevent moisture absorption on ceramic surfaces.
