Description

Detailed information organization of MPL-B540K-SJ24AA A-B servo motor,based on the provided search resources:

DESCRIPTION

MPL-B540K-SJ24AA is a low inertia AC servo motor designed by Allen Bradley for high-precision position and speed control in the industrial automation field.It adopts permanent magnet synchronization technology and is equipped with a single coil high-resolution encoder(supporting Hiperface protocol),which can achieve accurate position feedback.The motor is equipped with a 24V DC brake,suitable for scenarios that require rapid braking,and features a compact 165mm frame design for easy installation.

MPL-B540K-SJ24AA A A-B

Product parameters

model:MPL-B540K-SJ24AA

manufacturer:Allen-Bradley

Electrical and mechanical performance:

Rated voltage:400V AC.

Rated power:5.4 kW.

Rated speed:4000 rpm.

Continuous stall torque:172 pounds per inch(approximately 19.4 N·m).

Peak stall torque:420 pounds per inch(approximately 47.4 N·m).

Rotor inertia:0.014 lb·in·s²(approximately 0.00147 kg·m²).

Physical specifications:

Frame size:165 millimeters.

Magnet stack length:101.6 millimeters(4 inches).

Weight:Approximately 33 pounds(15 kg).

Encoder and Interface:

Encoder type:1024 Sin/Cos absolute value single loop encoder,supporting Hiperface protocol.

Connector:Circular bayonet connector,180°rotatable.

Product specifications

Design specifications:

Adopting a low inertia rotor design,it has a fast response speed and is suitable for high-speed dynamic applications.

Integrated single loop high-resolution encoder ensures position control accuracy.

Supports 24V DC brake and provides reliable braking function.

Protection and installation:

Protection level:default IP50,optional shaft seal can be upgraded to IP66(sealing kit needs to be purchased separately).

Installation method:IEC metric flange with free mounting holes(FF type),shaft key design for easy mechanical connection.

series

MPL-B540K-SJ24AA belongs to the Allen Bradley MPL series low inertia permanent magnet rotary servo motor.This series of motors is known for its high torque density,compact design,and reliability,covering a power range of 0.16-18.6 kW and supporting a rated speed of 8000 rpm,suitable for various industrial automation scenarios.

MPL-B540K-SJ24AA A A-B

characteristic

Performance advantages:

High precision and high response:Low inertia design combined with high-resolution encoder achieves fast dynamic response and precise positioning.

Efficient and energy-saving:Permanent magnet synchronous technology improves energy efficiency and reduces operating costs.

Durability:Using high-quality materials and craftsmanship to meet the stringent requirements of industrial environments.

Design features:

Integrated circular bayonet connector,simplifies wiring,and supports quick installation.

Optional shaft seal kit to enhance dust and moisture resistance.

Support Hiperface protocol to ensure high-speed and stable communication between the encoder and control system.

Action and use

effect:

Convert electrical signals into precise mechanical motion to achieve position,speed,and torque control of equipment.

Real time feedback is provided through a built-in encoder,supporting closed-loop control systems to ensure motion accuracy.

Purpose:

As the core executing component of industrial automation equipment,it drives mechanical components to complete precise actions.

Suitable for applications that require fast start stop,frequent commutation,or high-precision positioning.

application area

Industrial automation:used for production lines,assembly equipment,conveyor systems,etc.,to achieve precise motion control.

Robot technology:supports high-speed and high-precision movement of robot joints,improving work efficiency.

Packaging and Printing:Control roll feed,label positioning,etc.to ensure the stability of the production process.

Machine tools and metal processing:Drive cutting tools or workbenches to meet the needs of precision machining.

Other fields:Widely used in scenarios that require high dynamic performance and precise control,such as semiconductor manufacturing,textile machinery,etc.

MPL-B540K-SJ24AA A A-B

summarize

The MPL-B540K-SJ24AA A-B servo motor,with its low inertia,high precision,and reliable braking design,has become an ideal choice in the field of industrial automation,especially in applications that require fast response and precise positioning.Its compact structure and flexible configuration further enhance its applicability,making it suitable for various complex industrial scenarios.
