Description

HONEYWELL CC-TAID01 Analog Input Termination Assembly is a 16 channel differential analog input terminal board specifically designed for Honeywell Expertise®Design of PKS C series distributed control system.As a supporting hardware for the C-series analog input module,HONEYWELL CC-TAID01 provides a convenient and reliable interface for connecting analog signals from field sensors and transmitters,such as voltage(0-10V,4-20mA,0-5V,1-5V,etc.)and current signals.The main function of CC-TAID01 is to safely and reliably transmit these analog signals to the corresponding analog input modules(such as CC-PAIX series)for subsequent signal conversion and processing.The design of this terminal board takes into account the wiring requirements of industrial environments,providing clear terminal identification and convenient wiring methods,simplifying on-site installation and maintenance work.Although HONEYWELL CC-TAID01 Analog Input Termination Assembly does not have signal conversion function itself,it is a key component in building a stable and reliable analog input system,ensuring the accurate transmission of on-site signals to the control system.

Each channel of HONEYWELL CC-TAID01 Analog Input Termination Assembly supports differential input,which helps improve the ability to resist common mode interference and ensure the quality of signal transmission.This terminal board is usually installed on a DIN rail and equipped with spring clips or screw terminals,making it convenient for on-site engineers to perform wiring operations.The design of CC-TAID01 is compact and can effectively utilize control cabinet space in high-density I/O systems.As a Honeywell Expert®Part of the PKS system,HONEYWELL CC-TAID01 Analog Input Termination Assembly and Experimentation®The controller and I/O module are seamlessly integrated to jointly build a stable and efficient automation system.Although it does not possess intelligent features,its reliable physical connection performance is crucial for ensuring the data acquisition accuracy of the entire control system.

technical specifications

Product model:CC-TAID01

manufacturer:HONEYWELL

Product Type:IOTA-I/O Termination Assembly

Number of channels:16

Input Type:Differential Analog Voltage/Current Input

Terminal type:spring clip or screw terminal

Installation method:DIN rail installation

Working temperature:-40°C to+70°C

Humidity:5%to 95%relative humidity,non condensing

Main features and advantages

High channel density:HONEYWELL CC-TAID01 Analog Input Termination Assembly provides 16 differential analog input channels,which can connect a large number of field signals in a compact space.

Supports multiple analog signals:designed to connect various standard industrial analog voltage and current signals,depending on the connected analog input module.

Differential input:Each channel supports differential input,effectively improving the ability to resist common mode interference and ensuring the quality of signal transmission.

Convenient on-site wiring:Using spring clips or screw terminals,it is convenient for on-site engineers to perform fast and reliable wiring operations,reducing installation time.

Clear terminal identification:Each terminal has a clear identification,which facilitates users to connect signal lines correctly and avoids wiring errors.

Compact industrial design:suitable for high-density industrial control systems,saving control cabinet space.

With Expert®PKS seamless integration:as an expert®As part of the PKS system,HONEYWELL CC-TAID01 Analog Input Termination Assembly is perfectly compatible with Honeywell’s controllers and I/O modules.

application area

HONEYWELL CC-TAID01 Analog Input Termination Assembly,as a matching terminal board for analog input modules,is widely used in various industrial automation fields to connect signals from various analog sensors and transmitters on site

Process control:Connect the output signals of temperature,pressure,flow,liquid level and other transmitters.

Factory automation:Connect various analog sensors,such as displacement sensors,force sensors,etc.

Environmental monitoring:Connect the output signals of sensors such as temperature,humidity,and gas concentration.

Building automation:analog output connected to temperature,humidity sensors,and other environmental control devices.

Any requirement to reliably transmit on-site analog signals to Honeywell Expert®Application of PKS control system.

Related products

HONEYWELL CC-PAIX series analog input module:used in conjunction with CC-TAID01 terminal board to convert received analog signals into digital signals for control system processing.

HONEYWELL CC-TAIX series analog input terminal board:Honeywell Experion®Other analog input terminal boards in the PKS C series may differ in terms of channel count or characteristics.

HONEYWELL C300 Controller:Experion®The core control unit of PKS communicates with the analog input module through the I/O bus.

HONEYWELL FTE bus interface module:used to connect C300 controller and I/O module.

Various industrial analog sensors and transmitters,such as temperature transmitters,pressure transmitters,flow meters,etc.,serve as signal sources for the CC-TAID01 terminal board.

Installation and maintenance

Preparation before installation:Before installing HONEYWELL CC-TAID01 Analog Input Termination Assembly,please refer to the relevant Honeywell Expert®System installation manual and specification sheet for CC-TAID01.Ensure that the control cabinet is installed correctly and reserve sufficient DIN rail space.Securely install the CC-TAID01 terminal board onto the DIN rail.Carefully read the wiring diagram of the analog input module used in conjunction with CC-TAID01 and the wiring requirements of the field instruments,and prepare the corresponding signal cables.According to the channel definition and signal type,correctly connect the signal line of the field instrument to the terminal of CC-TAID01,ensuring the correct polarity and tightening the screw or inserting the spring clip correctly.

Maintenance suggestion:HONEYWELL CC-TAID01 Analog Input Termination Assembly is a passive component with low maintenance requirements.It is recommended to regularly check whether the installation of the terminal board on the DIN rail is stable,and whether the connection of the signal cable is reliable,without looseness or damage.Keep the terminal board clean to prevent dust and moisture from entering.Regularly check whether the wiring of on-site instruments is loose or corroded.

Product Guarantee

Honeywell provides standard quality assurance for its industrial automation products.HONEYWELL CC-TAID01 Analog Input Termination Assembly undergoes strict quality testing before leaving the factory to ensure compliance with relevant industry standards and Honeywell’s quality requirements.
