Description

RELIANCE SR3000 2SR40700 bus brake module is a key auxiliary component in the SR3000 series drive.It can effectively absorb excess energy generated by AC/DC servo motors during deceleration or load regeneration by having a built-in 700 W continuous power absorption capacity and up to 75 kW instantaneous energy absorption performance(within 0.5 seconds),avoiding DC bus voltage rise.

The working voltage of this module is adapted to a 460 VAC system environment and can be used in parallel with SR3000 drivers.It supports multi unit parallel connection to enhance the total energy absorption capacity and meet the requirements of high-power systems.The module is equipped with status indicator lights(P/S,SNB,FLT,ALM),24V control circuit,interface terminals,supports external overheating protection components,and adopts a forced air cooling system to effectively maintain stable operation.

Main features and advantages

High capacity can absorb

2SR40700 supports up to 700 W continuous and 75 kW instantaneous regenerative energy absorption,ensuring the stability of high-power servo/frequency conversion system busbars.

Compatible with 460 V system

Specially designed for 460 VAC industrial systems and corresponding SR3000 drivers,ensuring voltage matching and energy absorption efficiency.

Parallel expansion capability

The module supports parallel installation,which can enhance energy absorption capacity and achieve stronger system protection when multiple units work together.

Complete status monitoring

Provide four indicator lights for P/S,SNB(energy absorption),FLT(fault),ALM(alarm),as well as 24V control/status terminals for monitoring and integrated control.

Intelligent protection with automatic response

Integrated overheating and overload protection mechanism,supporting external temperature control circuit breaker,can automatically protect module safety in case of abnormalities.

Modular air-cooled structure

The internal forced air cooling design of the DC busbar is compact and space saving,ensuring long-term stable and reliable operation.

technical specifications

Product model:SR3000 2SR40700

Series:SR3000 Bus Snoobber Brake/Energy Absorption Module

Continuous energy absorption capacity:700 W

Instantaneous energy absorption capacity:75 kW(0.5 s)

Suitable voltage:460 VAC system

Maximum withstand voltage:750 VDC

Bus connection:+P,-N terminals

Control power supply:24V control circuit

Status indicator lights:P/S,SNB,FLT,ALM

Cooling method:forced air cooling(24V DC fan)

Working temperature:-10°C to+55°C

Environmental humidity:5-95%(without condensation)

Protection level:Installed inside the cabinet,in a non corrosive gas environment

application area

The RELIANCE 2SR40700 module is suitable for SR3000 series servo/variable frequency drive systems,especially in industrial scenarios such as high-power CNC machine tools,printing machinery,packaging equipment,and automated assembly lines that require frequent braking or reverse regeneration.Its good energy absorption capacity avoids bus overvoltage,improves driving safety and stability.In addition,supporting parallel expansion can meet the system requirements of over 50HP and is an important component of high-end servo application systems.

Related products

2SR20450:Suitable for bus brake units driven by 230 VAC,with 450 W continuous energy absorption.

Parallel 2SR40700:Two or more parallel combinations,suitable for systems above 100HP.

SR3000 main drive module:used in conjunction with the busbar energy absorption module.

AFI repair service:provides bridge deck repair and complete machine refurbishment services,with warranty included.

Installation and maintenance

Preparation before installation:Cut off the system power,wait for the DC bus to fully discharge(recommended≥5 minutes),and confirm that the drive is configured with 460 VAC.Connect 2SR40700 to the+P/-N terminals on the SR3000 bus,ensuring that the control circuit 24V,fan power supply,and alarm terminals are wired correctly.

Maintenance suggestion:Regularly check the fan speed and ventilation to ensure good heat dissipation;Monitor the status indicator lights and promptly handle ALM/FLT alarms;To improve energy absorption capacity,parallel modules can be added.At the same time,keep the module environment clean and avoid dust blocking the air duct.
