Description

EMERSON 1C31113G01 is a high-performance analog output module (AO module) specifically designed for Ovation DCS control systems. This module supports multiple analog output channels and is typically used to control field devices such as valves, frequency converters, regulators, etc. that require analog control signals. Having high precision, high stability, and strong anti-interference ability, it is one of the key modules in industrial field process control.

EMERSON 1C31113G01

?  Product Details

1C31113G01 belongs to Emerson’s Ovation control system product line and is a highly reliable analog output module. It adopts standard industrial signals (usually 4-20mA output), supports multi-channel independent control, and has complete diagnostic functions. This module can be used in conjunction with the control processor, IO power supply, and bus communication module in the Ovation control rack to build a complete DCS automation system.

Functional Features

?  Multi channel analog output: supports multiple independent 4-20mA outputs

?  Hot swappable capability: supports online replacement without power outage

?  Self diagnostic function: Real time detection of channel status to ensure system reliability

⚙️  High anti-interference design: suitable for strong interference scenarios such as power plants and chemical industries

?  Modular design: easy to replace and expand the system

?  Highly compatible with Ovation controllers, plug and play without additional configuration required

?  Technical specifications and parameters

Product model: 1C31113G01

Brand: EMERSON

System Platform: Ovation DCS Control System

Function type: Analog Output (AO) module

Number of channels: usually 8 or 16 channels (depending on the version)

Signal type: 4-20mA DC output (can support 0-20mA)

Output accuracy: ± 0.05% FSR (typical)

Load capacity: Maximum load of 750 Ω

Response time:<100ms>

Isolation method: Channel to channel, power supply and system are fully isolated

Installation method plug-in, compatible with Ovation standard I/O rack

Working temperature: 0 ℃~60 ℃

The power supply voltage is provided by the system (± 24VDC or ± 5VDC)

Module diagnostic channel disconnection, short circuit detection, self detection function

Certified CE, RoHS, UL (specific batches can be checked)

?  application area

1C31113G01 is mainly used in various process control systems constructed by Ovation DCS system, including but not limited to:

⚡  Automation system for thermal power plants/hydropower stations/nuclear power plants

?  Petrochemical process control

?  Automation of water treatment/sewage treatment

?️  Pipeline remote monitoring system

?  Pharmaceutical/Food/Metallurgical Automation Process

?  Automatic control of urban infrastructure (subway, smart city)

?  Related product recommendations

1C31113G02: Same series high channel version AO module

1C31110G03: Analog Input Module (AI)

1C31234G01: Digital Input Module (DI)

1C31227G01: Digital Output Module (DO)

1C31125G02: Communication adaptation module

1C31129G03: Power module

EMERSON 1C31113G01

?️  Installation and maintenance recommendations

Installation Tip:

The module should be correctly inserted into the corresponding I/O rack, paying attention to direction and positioning

Static protection treatment is required before use to avoid damage to the components

Cooperate with the correct matching terminal cable to ensure correct wiring of current output

Maintenance suggestion:

Regularly check whether there is drift in the channel output

If there is an output abnormality, Ovation diagnostic tool can be used to quickly locate it

Support hot swappable replacement, but it is recommended to operate in the maintenance window
