EMERSON 5X00790G01: This Emerson Ovation Compact Controller (OCC100) is the “tough little cannon” in the field of industrial automation! It perfectly combines the compact and robust nature of PLC with the powerful functionality of Ovation DCS, designed specifically for space constrained or decentralized applications. Processor: Xilinx Zynq SoC dual core CPU, Communication: Supports multiple industrial Ethernet protocols, Deployment: Supports Simplex and redundant configurations. Specializing in various on-site control challenges, simplifying system architecture, and improving control efficiency. Don’t look at it, it’s original and authentic, with worry free after-sales service. Our home is your reliable support for industrial automation, there’s no problem!

EMERSON 5X00790G01 Product Overview

Brother, the EMERSON 5X00790G01 you asked about this time is really versatile in Emerson Ovation Distributed Control System (DCS) – it is the Ovation Compact Controller (OCC100). As the name suggests, this thing condenses Ovation’s proven powerful control capabilities into a smaller and more robust “box”, retaining both the flexibility and durability of PLC (Programmable Logic Controller) and the advanced control algorithms and seamless integration advantages unique to Ovation DCS.

The emergence of EMERSON 5X00790G01 is mainly to meet the needs of those who need to deploy control functions far away from the central control room or in industrial sites with very limited space. Traditional Ovation controllers may be larger in size and more suitable for operation in central control rooms or large cabinets. The compact controller EMERSON 5X00790G01 can be directly installed near on-site equipment, such as a pumping station, an independent cooling unit, or even inside the tower base of a wind turbine. It can directly process local I/O signals, execute control logic, and communicate with the entire Ovation DCS system through Ethernet and other methods to upload data and issue control instructions.

Here comes the value of EMERSON 5X00790G01: it not only reduces remote cabling costs, simplifies system architecture, but also improves control response speed and reliability for decentralized assets. Whether it’s the upgrade and renovation of old PLC systems or the distributed deployment of new projects, EMERSON 5X00790G01 is a very attractive choice that can help you build a modern control system that is both economical and efficient, flexible and reliable!

EMERSON 5X00790G01

EMERSON 5X00790G01 Technical Specifications

Product model: 5X00790G01

Manufacturer: Emerson

Product Type: Ovation Compact Controller (OCC100)

Processor: Xilinx Zynq SoC, typically a 667 MHz ARM Cortex-A9 dual core CPU

Memory: 256 MB DDR3 SDRAM, 1GB USB flash drive (or equivalent storage)

Architecture: Supports Simplex (standalone) and Redundancy configurations

Communication interface: Ethernet ports (usually 2, 10/100/1000 Base-T, RJ45 connectors)

Supporting protocols: Supports multiple industrial protocols such as Modbus TCP/RTU, DNP3, OPC UA, IEC 60870-5-101/103/104, BACnet, etc

I/O compatibility: Compatible with all Ovation I/O modules, including dedicated modules

I/O capacity: expandable to hundreds of I/O points, depending on configuration and application requirements

Control functions: advanced control algorithms such as PID control, Boolean logic, data acquisition, sequence control, etc

Power supply 24 VDC (DC), typical power consumption is about 5.8W, maximum power consumption is about 6.4W

Installation method: DIN rail installation, usually used in conjunction with a dedicated controller base, supports hot swapping

Working temperature: -20 ° C to+70 ° C (-4 ° F to+158 ° F)

Storage temperature: -40 ° C to+85 ° C (-40 ° F to+185 ° F)

Relative humidity: 5% to 95% non condensing

Certification usually complies with industry standards such as IEC 61131-2 and CE marking

Physical size and weight: Compact design, specific size and weight depend on the combination of controller and base, usually lightweight

Main features and advantages

The EMERSON 5X00790G01 Ovation compact controller is unbeatable in the industrial field, and it has several real “hardcore” advantages!

Firstly, its compact design and flexible deployment are tailor-made for modern industry. Traditional DCS controllers are not small in size and require specialized control rooms or large cabinets. But the EMERSON 5X00790G01 controller, with its compact size, is powerful and can be directly installed near on-site equipment, even in existing control cabinets with narrow spaces. This is like moving Ovation’s’ brain ‘directly to the’ frontline battlefield ‘, greatly simplifying on-site wiring, reducing installation costs and complexity. Think about it, with so many cables, now only a few communication lines are needed, saving money and time, that’s not a small amount! This flexibility is like a “miracle” for the management of decentralized assets such as distributed energy, water treatment pumping stations, and oil and gas gathering stations.

Secondly, EMERSON 5X00790G01 achieves a perfect integration of DCS level control and PLC level ruggedness. It has the “noble blood” of Ovation DCS flowing in its bones, equipped with advanced PID (proportional integral derivative) control, Boolean logic, data acquisition and other complex control functions, and can handle complex industrial processes. But at the same time, its physical design is as sturdy and durable as a PLC, capable of withstanding common vibrations, impacts, and extreme temperatures in industrial sites, and even stable operation within a wide temperature range of -20 ° C to+70 ° C. This means that you can enjoy the high performance and unified management of the Ovation platform without worrying about the controller falling off the chain in harsh environments, ensuring the continuous stability of the production process.

Furthermore, EMERSON 5X00790G01 also possesses exceptional communication capability and system integration. It can not only seamlessly integrate with the main Ovation system, but also transmit data and control commands through standard Ethernet ports. What’s even more impressive is that it comes with multiple third-party industrial communication protocols, such as Modbus TCP/RTU, DNP3, OPC UA (Unified Architecture), IEC 60870-5-101/103/104, BACnet (Building Automation and Control Network Protocol), and more. This means that your EMERSON 5X00790G01 can easily communicate with various brands of PLCs, RTUs (remote terminal units), instruments, and even building systems in the factory, completely breaking down information silos and achieving true data interconnectivity across the entire factory. This powerful integration capability makes your automation system smarter and more efficient, laying a solid foundation for future digital transformation! Moreover, it also supports Simplex (standalone) and Redundancy (redundant) configurations, ensuring the ultimate reliability of critical applications. Even if one side has a problem, the other side can immediately take over, and production will never stop, giving you peace of mind!

application area

The EMERSON 5X00790G01 Ovation compact controller has a “big stage” that is not limited to large-scale centralized control scenarios. It is also “shining brightly” in industrial fields where there is an urgent need for distributed control, real-time on-site response, and compact solutions!

Firstly, in the power and energy industry, especially in the management of decentralized energy assets, it is simply the ‘best choice’. For example, in a wind power plant, each wind turbine has its own control unit. The EMERSON 5X00790G01 can be directly installed on the tower base of the wind turbine, responsible for local control tasks such as blade pitch, yaw control, generator start stop, etc., and communicates with the central SCADA or Ovation DCS through the network. Similarly, it can provide efficient and reliable on-site control in small hydroelectric power plants, solar power plants, microgrids, and distributed energy storage systems (Battery Energy Storage Systems, BESS).

Secondly, in water treatment and wastewater treatment plants, especially in scenarios with a large number of dispersed pump stations, valve chambers, or remote monitoring points, the advantages of EMERSON 5X00790G01 are very obvious. It can be deployed in remote pumping stations to monitor water level, flow rate, and pressure in real time, and control pump start stop and valve opening and closing according to central instructions, thus avoiding long-distance analog wiring and greatly reducing construction and maintenance costs.

Furthermore, in the oil and gas industry, EMERSON 5X00790G01 is widely used in oil and gas gathering stations, pipeline control, remote wellheads, and other places. It can be directly deployed on site for natural gas metering, pressure control, valve operation, etc., and upload data to the Ovation platform in the center. In addition, EMERSON 5X00790G01 also provides flexible and economical solutions for large and dispersed process factories such as metallurgy and chemical engineering, or projects that require the gradual upgrade of traditional PLC systems to a more unified DCS platform. It can help you achieve seamless integration and data sharing between different control layers, and improve the automation and intelligence level of the entire production process.

EMERSON 5X00790G01

Related products

As a compact Ovation controller, EMERSON 5X00790G01 typically works in conjunction with other components of the Emerson Ovation system to build a complete distributed control solution

EMERSON 5X00791G01: Ovation Compact Controller Base (OCC100 Base), 5X00790G01 needs to be installed on this base to function properly.

EMERSON 5X00096G01: Ovation S-series controller, as a larger or more central controller, for network communication and data exchange with 5X00790G01.

EMERSON 5X00419G02: Ovation Ethernet Link Controller (ELC) module, through which 5X00790G01 may connect to the main Ovation network.

EMERSON 5X00453G01: Ovation Remote Node Interface (RNI) module, in some distributed architectures, 5X00790G01 may serve as a smaller local controller, accessing higher-level remote I/O networks through RNI.

EMERSON 5X00059G01: Ovation I/O chassis/carrier, although 5X00790G01 itself is a controller, the I/O modules it manages will still be installed in Ovation’s I/O carrier.

EMERSON 5X00034G01: Ovation system power module provides stable power to the remote cabinet or I/O carrier where 5X00790G01 is located.

EMERSON 5X00106G02: Ovation HART high-performance analog input module, 5X00790G01 can directly manage and read data from these I/O modules.

EMERSON 5X00070G04: Ovation discrete input module, used to collect digital quantity status.

EMERSON 5X00062G01: Ovation discrete output module, used to control digital devices.

Industrial Ethernet switch/router: 5X00790G01 will connect to these network devices to build the factory Ethernet backbone, enabling high-speed communication with operator stations, engineer stations, and other systems.

Installation and maintenance

Preparation before installation: When you are preparing to install the EMERSON 5X00790G01 compact controller, please be sure to consider it as the “commander” in the distributed control system, as any negligence may affect the entire system. Firstly, ensure that all relevant power sources have been completely cut off and strict “lockout/tagout” measures have been taken, which is the “iron law” to ensure personal safety and equipment integrity. Due to the high sensitivity of EMERSON 5X00790G01 to electrostatic discharge (ESD), operators must wear anti-static gloves or wristbands throughout the entire process and ensure that the workbench and themselves are well grounded to avoid irreversible damage to the module caused by ESD. Carefully verify that the module model 5X00790G01 is completely consistent with the specific version, CPU type, and communication protocol requirements required by your system to avoid issues caused by version incompatibility. During installation, carefully align the EMERSON 5X00790G01 controller with its dedicated base (usually 5X00791G01) and DIN rail, insert it vertically and smoothly until the module is fully secured in place, and ensure that all connectors have tight and reliable electrical connections to the base. Finally, connect all power cords, Ethernet cables, and I/O module cables correctly, and check if the physical layer connections are functioning properly.

Maintenance suggestion: For core controller modules like EMERSON 5X00790G01, the focus of daily maintenance is on “environmental protection” and “software health monitoring”. Firstly, it is crucial to keep the interior of the cabinet where the controller is located clean. Regularly remove dust and debris accumulated on the surface of modules and inside the chassis to ensure that all ventilation openings and cooling systems (if applicable) are functioning properly, as overheating is the “number one killer” that causes electronic components to fail prematurely. Regularly inspect all communication cables (Ethernet cables, I/O connection wires) and wiring terminals connected to EMERSON 5X00790G01 to ensure that all connections are secure, free of looseness, and corrosion, especially the physical integrity of industrial grade Ethernet connectors. In addition, make full use of the powerful online diagnostic function provided by the Ovation DCS system and the status indicator lights of EMERSON 5X00790G01 itself to regularly check the controller’s operating status, CPU load, memory usage, network traffic, error counting, and system alarm information. These diagnostic information can promptly detect potential issues such as controller performance degradation, communication abnormalities, I/O failures, etc., helping you with predictive maintenance, transforming passive repairs into proactive prevention, maximizing system availability and reducing unplanned downtime, ensuring the continuous and stable operation of the entire distributed control system.
