Description

CC-PUIO31 is a high-performance Universal Input/Output Module (Universal I/O Module) widely used in process automation systems in the Honeywell Expert PKS/C300 system. It integrates processing capabilities for multiple signal types and has highly flexible I/O channel configuration capabilities, bringing significant engineering convenience and cost-effectiveness to users. It is an important component of the “modular+remote deployment” architecture of modern DCS systems.

?  Product Details

Honeywell CC-PUIO31 is a highly representative member of the I/O family in the C300 control system. This module has the capability of * * Programmable Input/Output (I/O) * * and supports configuring a single channel as AI, AO, DI, or DO through software to meet various on-site needs.

Based on Honeywell’s Universal Channel Technology architecture, it achieves higher density, flexible configuration, simplified wiring, and low maintenance costs at the I/O system level, making it particularly suitable for continuous and batch process control scenarios with high integration, reliability, and safety levels.

?  Technical specifications and parameters

Model: CC-PUIO31

Brand: Honeywell

System: Expert PKS/C300

Module type: Universal I/O module

Number of channels per module: 16 channels (each channel is independently configured)

Channel type support: AI/AO/DI/DO, single channel configurable

Module installation method: plug-in (installed on the I/O motherboard)

Communication interface: FTE (Fault Tolerant Ethernet) or I/O link

Redundancy support: Supports dual-mode redundancy configuration

Channel isolation: Optoelectronic isolation between channels, strong anti-interference ability

Power supply requirement: 24V DC power supply (system bus power supply)

Hot swappable support: supports hot swappable replacement without shutting down

Working temperature range: -20 ° C to+60 ° C

Electrical safety level: meets Class 1 Div 2/ATEX explosion-proof standards (some models)

?  Core features and advantages

?  Flexible channel configuration

Each channel can be configured as analog/digital input/output through control strategies, truly achieving integrated universal I/O.

?  Reduce wiring and construction costs

No need to purchase specialized modules for different I/O types, greatly reducing the complexity of I/O cabinet design and inventory types.

?  Module hot plugging

Support module replacement and maintenance during operation, reduce downtime, and improve system availability.

?  Remote intelligent management

Seamless integration with Honeywell FTE architecture, supporting remote diagnosis, configuration, and upgrade, comprehensively improving operational efficiency.

?  Simplify the project engineering cycle

The universal module simplifies design and accelerates debugging, especially in EPC projects, which can effectively reduce project duration and rework rate.

?  Application scenarios

CC-PUIO31 is widely used in the following process control fields:

Petroleum Refining and Petrochemical Equipment (Continuous Control+Remote Distributed I/O)

Natural gas liquefaction station and LNG transfer station

Auxiliary systems for thermal power plants and combined cycle units

Cleanliness control areas for pharmaceuticals, biotechnology, food processing, etc

Fine chemical reaction equipment and tank area

Automated systems for municipal water management and sewage treatment plants

SIS peripheral monitoring signals in redundant high security scenarios

?  Related product recommendations

CC-PCNT01: Control network interface module, supporting I/O link communication

CC-PUIO01: Old version of universal I/O module, CC-PUIO31 is an upgraded version

CC-TDIL01: Digital Input Module

CC-TDOR01: Digital Output Module

CC-TAIX01: Analog Input Module

CC-TAOX01: Analog Output Module

CC-PWRR01: System Power Redundancy Module

FTE201: FTE Network Switching Module

MU-TDID12: DI module of Legacy system, supporting alternative solutions

?️  Installation and commissioning suggestions

It is recommended to configure the Honeywell C300 system architecture uniformly through the Expert software;

The installation location should be dust-proof, moisture-proof, and avoid areas with strong electrical interference;

All channel configurations must strictly match the type of on-site instruments and indicate the signal routing numbers;

Please complete channel type verification and wiring insulation testing before powering on;

It is recommended to cooperate with Honeywell’s on-site dedicated motherboard for plug-in testing to ensure reliable contact;

After debugging, lock the module to prevent system disturbance caused by incorrect insertion and removal.
