The Eaton XVS-440-10MPI-1-1AD is a compact, sensorless vector variable frequency drive (VFD) engineered for precise speed and torque control of three-phase AC motors. Designed for industrial automation, this 10 HP (7.5 kW) drive simplifies deployment in material handling, HVAC, and light machinery with its space-saving design and intuitive keypad programming. The XVS-440-10MPI-1-1AD features built-in PID control, dynamic braking, and automatic motor adaptation, enabling optimal performance without encoder feedback. Its robust construction supports 200–240 V AC single-phase input with 3-phase output, while conformal-coated PCBs ensure reliability in dusty or humid environments. With embedded Modbus RTU communication and multiple I/O options, the Eaton XVS-440 series seamlessly integrates into PLC networks for energy-efficient motor management across diverse applications.
Eaton XVS-440-10MPI-1-1AD
Technical Specifications
| Parameter Name | Parameter Value |
| Product Model | XVS-440-10MPI-1-1AD |
| Manufacturer | Eaton |
| Product Type | Variable Frequency Drive (VFD) |
| Rated Power | 10 HP (7.5 kW) |
| Input Voltage | 1-phase 200–240 V AC (+10%/-15%) |
| Output Voltage | 3-phase 0–230 V AC |
| Output Current | 32 A |
| Control Modes | Sensorless Vector Control (SVC), V/f |
| Switching Frequency | 2–16 kHz (adjustable) |
| Communication | Modbus RTU (RS-485) |
| Digital Inputs | 3 programmable (24 V DC) |
| Analog Inputs | 1x 0–10 V, 1x 0/4–20 mA |
| Relay Outputs | 1 programmable (250 V AC/30 V DC) |
| Protections | Overcurrent, Overtemp, Short Circuit, Undervoltage |
| Enclosure Rating | IP20 |
| Operating Temperature | -10°C to +50°C (derating >40°C) |
| Dimensions | 198 mm × 165 mm × 172 mm (H×W×D) |
| Weight | 3.2 kg |
Main Features and Advantages
Optimized Motor Control: The Eaton XVS-440-10MPI-1-1AD employs sensorless vector technology for 150% starting torque at 0.5 Hz, ensuring smooth conveyor starts under load. Auto-tuning identifies motor parameters in 30 seconds, eliminating manual configuration.
Energy-Saving Intelligence: Embedded Eco Mode adjusts voltage-to-frequency ratios dynamically, reducing energy consumption by 15–30% in centrifugal pump/fan applications. Sleep/wake functions halt motors during low-demand periods.
Simplified Integration: Pre-configured PID loops for pressure/flow control accept feedback directly from analog inputs. Built-in dynamic braking resistors prevent overvoltage faults during rapid deceleration.
User-Friendly Operation: Backlit LCD keypad displays real-time kW, RPM, and fault logs. Copy/paste functionality clones parameters between drives via USB.
Application Areas
The Eaton XVS-440-10MPI-1-1AD excels in light industrial automation. In material handling, it controls conveyor belt speeds for packaging lines while preventing jams with torque limiting. HVAC systems leverage its PID control for building air pressure regulation via inverter fans. For food processing, the drive manages mixer agitation rates without gearboxes, enabling recipe-based speed profiles. Water treatment plants deploy it for chemical dosing pump accuracy (±1% flow stability). Small CNC machines utilize its dynamic braking for rapid spindle stops.
Related Products
Eaton XVS-440-10TPI-1-1AD: 10 HP variant with EtherNet/IP protocol
Eaton DG1 CURR Dynamic braking resistor (50W) for XVS-440
Eaton 1P 89346: EMC filter for CE compliance
Eaton OV-2-440-10: Operator interface with potentiometer
Eaton MCS-Titan-10-230: Motor starter for backup bypass
Eaton XVS-440-10MPI-1-1AD
Installation and Maintenance
Pre-installation preparation: Verify motor compatibility (IEC 60034-30-1). Ensure input voltage stability (±5%). Ground VFD chassis with <10>100 mm gap).
Maintenance recommendations: Clean air vents quarterly with compressed air. Monitor DC bus voltage monthly; deviations >15 V indicate capacitor aging. Update firmware via Eaton DriveXpert software annually.
