Description

The EATON XV-440-10TVB-1-13-1 is a premium variable frequency drive (VFD) from Eaton’s XV-440 series, engineered for precision motor control in industrial automation. Designed for 10 HP (7.5 kW) applications, this VFD features advanced sensorless vector control (SVC) technology, enabling ±0.2% speed regulation without feedback devices. As part of Eaton’s modular drive ecosystem, the EATON XV-440-10TVB-1-13-1 integrates seamlessly with PLCs and SCADA systems via embedded Modbus RTU/RS485, reducing commissioning time by 30% compared to conventional drives. Its compact IP20-rated enclosure optimizes panel space while supporting dynamic braking for high-inertia loads.

Targeting water treatment, material handling, and HVAC applications, this drive delivers exceptional torque control (150% starting torque, 200% overload for 3 seconds) while minimizing harmonic distortion through DC choke integration. The EATON XV-440-10TVB-1-13-1 includes built-in Class A EMC filters, eliminating the need for external components to meet electromagnetic compatibility standards. Energy optimization algorithms automatically adjust voltage-to-frequency ratios, achieving up to 15% energy savings in centrifugal pump and fan applications.

Technical Specifications

Main Features and Advantages

Dynamic Performance: The EATON XV-440-10TVB-1-13-1 delivers industry-leading torque response with near-zero speed fluctuation (±0.2%) under load variations. Its auto-tuning function identifies motor parameters in<15>

Energy Intelligence: EcoMode algorithms reduce magnetizing current by 30% during light loads, while adaptive PWM minimizes switching losses. Built-in energy calculators provide real-time kWh consumption data, enabling precise cost tracking.

Robust Design: Conformal coating protects PCBs against humidity and corrosive atmospheres (ISO 12944 C3). The EATON XV-440-10TVB-1-13-1 withstands voltage dips down to 50% for 0.5 seconds without tripping, critical for grid instability regions.

User-Centric Engineering: Backlit LCD keypad stores 10 parameter sets for rapid configuration changes. Embedded PLC functionality allows standalone operation without external controllers. DIN-rail mounting simplifies installation in crowded panels.

Application Field

In water treatment plants, the EATON XV-440-10TVB-1-13-1 optimizes pump control with its PID loop controller, maintaining constant pressure despite flow variations while preventing water hammer through soft pipe-fill routines. HVAC systems leverage its fan law algorithms to reduce energy consumption in air handling units (AHUs), with automatic derating above 40°C ambient temperatures.

Material handling applications benefit from the drive’s S-curve acceleration profiles, preventing cargo slippage on inclined conveyors. For textile machinery, the EATON XV-440-10TVB-1-13-1 ensures tension control via torque pre-set functions, synchronizing multiple motors without encoders. In food processing, its washdown-ready design (conformal coating + stainless steel heatsink) withstands high-pressure cleaning.

Related Products

EATON XV-440-10TVB-1-10-1: 5 HP version for smaller pumps/fans

EATON XV-BRK-440-10: Dynamic braking resistor kit

EATON XV-COM-ENET: Ethernet/IP communication module

EATON XV-OPP-440: Operator panel with recipe management

EATON XV-SFT-STARTER: Configuration software suite

EATON XVF-440-10-10: Flange-mounted variant for motor integration

EATON XVL-440-10: Line reactor for harmonic mitigation

Installation and Maintenance

Pre-installation preparation: Verify input voltage compatibility (380–480V 3-phase) and ensure minimum 100mm clearance above/below the EATON XV-440-10TVB-1-13-1 for airflow. Use copper conductors (min. 14 AWG) with 75°C rating for power terminals. Ground impedance must be<0>

Maintenance recommendations: Clean air vents quarterly using low-pressure (<15>15% indicate capacitor aging. For long-term storage (>2 years), reform capacitors using controlled ramp-up procedure. Update firmware annually via XV-SFT-STARTER software to maintain performance.<!--15-->
