The FOXBORO FPS400-24 P0922YU is a high-reliability, redundant-capable power supply module engineered for the Foxboro I/A Series distributed control system (DCS). As a critical infrastructure component, the FOXBORO FPS400-24 P0922YU converts standard AC mains input into a tightly regulated 24V DC output to power I/O modules, fieldbus interfaces, and controller backplanes within I/A Series cabinets. Its design emphasizes continuous availability, featuring hot-swap capability, N+1 redundancy support, and comprehensive protection against overvoltage, overload, and short-circuit conditions.
Positioned as a core element of mission-critical process automation architectures, the FOXBORO FPS400-24 P0922YU ensures stable power delivery even in electrically noisy or thermally demanding environments such as oil refineries, chemical plants, and power generation facilities. With a rated output of 10A at 24V DC and high conversion efficiency, it minimizes heat generation while maximizing energy utilization. The FOXBORO FPS400-24 P0922YU integrates seamlessly into standard I/A Series chassis (e.g., FBM20x racks) and communicates health status via front-panel LEDs and optional diagnostic backplane signals—enabling predictive maintenance and rapid fault isolation without system shutdown.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | FPS400-24 P0922YU |
| Manufacturer | FOXBORO (an Emerson Automation Solutions brand) |
| Product Type | Redundant AC/DC Power Supply Module for I/A Series DCS |
| Input Voltage | 85–264 VAC, 47–63 Hz (universal input) |
| Output Voltage | 24 VDC ±1% |
| Output Current | 10 A continuous |
| Total Output Power | 240 W |
| Efficiency | >85% typical |
| Redundancy Support | N+1 parallel operation with current sharing |
| Protection Features | Overvoltage, overcurrent, short-circuit, thermal shutdown |
| Operating Temperature | 0°C to +60°C |
| Mounting | Slide-in module for I/A Series FBM20x/FBM24x backplanes |
Main Features and Advantages
High availability through redundancy and hot-swap: The FOXBORO FPS400-24 P0922YU supports N+1 redundant configurations, allowing multiple units to share load current and automatically compensate if one fails. Combined with hot-swap capability, this enables maintenance or replacement without interrupting power to critical I/O or controllers—essential for 24/7 process operations where unplanned downtime is unacceptable.
Precision power regulation and low noise: Delivering 24V DC with ±1% regulation and minimal ripple (<50>FOXBORO FPS400-24 P0922YU ensures clean power for sensitive analog I/O modules and digital logic circuits. This stability prevents signal drift in 4–20 mA loops and reduces bit errors in fieldbus communications, directly enhancing measurement accuracy and control reliability.
Robust protection and diagnostic visibility: The FOXBORO FPS400-24 P0922YU includes multi-layer protection against input surges, output shorts, and internal overheating. Front-panel LEDs indicate AC OK, DC OK, and FAULT status, providing immediate visual feedback for technicians. In redundant setups, the module participates in backplane-based health monitoring, allowing the I/A Series workstation to log power events and trigger alarms before failures escalate.
Global compliance and ruggedized design: Certified to UL 61010-1, CSA C22.2 No. 61010-1, CE, and conforming to IEC 61326 for EMC immunity, the FOXBORO FPS400-24 P0922YU operates reliably in harsh industrial settings. Its convection-cooled, fanless design eliminates moving parts, reducing maintenance needs and increasing mean time between failures (MTBF) to over 100,000 hours.
Application Field
The FOXBORO FPS400-24 P0922YU is deployed across continuous-process industries where power integrity directly impacts safety, environmental compliance, and production continuity. In petroleum refineries, it powers I/O subsystems that monitor reactor temperatures, control distillation column reflux, and manage emergency shutdown valves—applications requiring uninterrupted 24V DC to maintain fail-safe states during grid fluctuations. The redundancy feature of the FOXBORO FPS400-24 P0922YU ensures these safety instrumented systems (SIS) remain energized even during partial power unit failure.
In chemical and pharmaceutical manufacturing, the FOXBORO FPS400-24 P0922YU supplies clean, stable power to precision analog input modules measuring pH, conductivity, and flow rates. Any voltage ripple or dropout could corrupt sensor readings, leading to batch rejection or off-spec product. Similarly, in power plants, the FOXBORO FPS400-24 P0922YU supports turbine control panels and boiler management systems where millisecond-level response and power resilience are non-negotiable. Its global certifications also make it suitable for offshore platforms and mining operations with stringent electrical safety requirements. Across all these sectors, the FOXBORO FPS400-24 P0922YU serves as the silent but indispensable foundation of reliable, high-integrity automation.
Related Products
FPS400-12 P0922YT: 12V DC variant of the same series; used for legacy I/O modules requiring lower voltage
FBM207: I/A Series discrete input module; commonly powered by FPS400-24 P0922YU in safety interlock systems
FBM242: High-density analog output module; relies on stable 24V from FPS400-24 P0922YU for 4–20 mA accuracy
FIM02: Fieldbus Interface Module; requires clean DC power from FPS400-24 P0922YU for FOUNDATION Fieldbus communication
P0916ZZ: I/A Series power distribution backplane; provides mechanical and electrical interface for FPS400-24 P0922YU
FPS400-24 P0922YV: Updated revision with enhanced diagnostics; backward compatible with P0922YU mounting
CPM02: Controller Processing Module; depends on redundant FPS400-24 P0922YU units for continuous operation
Installation and Maintenance
Pre-installation preparation: Before installing the FOXBORO FPS400-24 P0922YU, verify compatibility with the target I/A Series chassis (e.g., FBM20x rack with P0916ZZ backplane). Ensure the AC feed meets voltage and grounding requirements per local codes. Slide the module fully into its designated slot until the retention latch engages—do not force insertion. Confirm that adjacent power supplies (if used in redundancy) are of the same model and firmware revision to ensure proper current sharing.
Maintenance recommendations: Routinely inspect the status LEDs on the FOXBORO FPS400-24 P0922YU: green AC OK and DC OK indicate normal operation, while a red FAULT LED signals internal issues. In redundant arrays, monitor load balance via the I/A Series diagnostic tools to detect aging units. Although the FOXBORO FPS400-24 P0922YU is fanless and requires no routine cleaning, ensure cabinet ventilation remains unobstructed to prevent thermal derating. When replacing a failed unit, use the hot-swap procedure—remove the faulty module while the system is live and insert the pre-tested spare without disrupting other components. Always keep a matched spare FOXBORO FPS400-24 P0922YU in inventory to maintain redundancy integrity.
