The ABB SC560 3BSE008105R1 is a high-speed PROFINET IRT (Isochronous Real-Time) slave module designed for ABB’s S800 I/O platform, enabling deterministic integration of field devices into Industry 4.0 automation networks. This module bridges ABB’s distributed I/O systems with PROFINET-enabled PLCs (e.g., Siemens SIMATIC, ABB AC 800M), supporting cycle times as low as 250 µs for motion control and precision processes. The ABB SC560 features dual-port switch technology for linear, ring (MRP), or star topologies, while its integrated FPGA handles real-time data processing independently of the host controller. With SIL 3 readiness (via PROFIsafe) and –40°C to +70°C operational range, it excels in demanding applications from automotive robotics to power distribution.
ABB SC560 3BSE008105R1
Technical Specifications
| Parameter | Value |
| Product Model | SC560 (3BSE008105R1) |
| Manufacturer | ABB |
| Product Type | PROFINET IRT Slave Interface |
| Protocol Support | PROFINET Conformance Class C (IRT), PROFIsafe |
| Data Rate | 100 Mbps (auto-negotiating) |
| Cycle Time | ≤250 µs (IRT), ≤1 ms (RT) |
| I/O Capacity | Up to 1440 bytes input/output |
| Topologies | Line, Star, MRP (Media Redundancy Protocol) |
| Isolation | 1500 V AC (field-to-backplane) |
| Connectors | 2 x RJ45 (IP20) with integrated switch |
| Diagnostics | Port-level LEDs (LINK/ACT, ERROR) |
| Power Supply | 5 V DC via S800 backplane |
| Operating Temperature | –40°C to +70°C |
| Certifications | IEC 61131, UL 61010, cULus |
Main Features and Advantages
Deterministic performance:
Hardware-based IRT synchronization via FPGA ensures jitter <1>
Supports 512 I/O variables per device with 31.25 µs update cycles
Network resilience:
MRP ring redundancy guarantees <10>
Integrated switch eliminates external infrastructure
Safety integration:
PROFIsafe profile enables SIL 3 safety logic without additional wiring
Channel-level diagnostics (wire break, short circuit) via PLC alarms
Deployment agility:
Automatic device replacement (LLDP) simplifies module swaps
GSDML file integration in TIA Portal/Engineering Studio
Application Field
The ABB SC560 3BSE008105R1 drives Industry 4.0 connectivity:
Automotive Manufacturing: Synchronizes robotic welding arms via PROFINET IRT
Packaging Machinery: High-speed servo control for filling lines (≤250 µs cycles)
Pharmaceuticals: SIL 3-compliant safety interlocks in tablet press control
Energy: Grid protection relay integration with AC 800M controllers
Water Treatment: MRP ring networks for pump station redundancy
Related Products
PM891: AC 800M controller with PROFINET IRT master capability
SD822: 16-Channel Digital Input Module for S800 integration
SA803: Analog Input Module with HART and PROFIsafe
TB801: Base unit for SC560 mounting
CI871: PROFINET controller interface for AC 800M
SC565: Enhanced version with 2-port Gigabit uplink
ABB Ability™ CMS: Condition monitoring software
ABB SC560 3BSE008105R1
Installation and Maintenance
Pre-installation preparation: Validate network topology (max. 100 nodes per segment). Assign device names via TIA Portal/Primary Setup Tool. Set MRP roles (Client/Ring Manager) for redundancy. Ground backplane to <0> Maintenance recommendations: Monitor switch diagnostics via PLC web interface. Update firmware during outages using SD card slot. Clean RJ45 ports quarterly with compressed air. Replace modules after 10+ years or LED fault indication.
