The ABB XVC517AE10 3BHB004744R0010 is a high-availability Ethernet communication module designed for ABB’s AC 800M PLC platform, delivering seamless industrial network integration in mission-critical automation systems. As part of ABB’s Control Network family, this module enables real-time data exchange between controllers, HMI stations, and enterprise systems via dual-redundant Gigabit Ethernet ports. The ABB XVC517AE10 supports PROFINET IRT, Modbus TCP/IP, and OPC UA protocols, making it ideal for synchronized motion control, process automation, and power management applications. Its integrated switch functionality allows daisy-chaining of devices without external hardware, reducing cabling complexity.
Engineered for 24/7 operation, the ABB XVC517AE10 3BHB004744R0010 features hardware-based redundancy with <5ms>ABB XVC517AE10 provides deterministic performance for applications demanding SIL 3 safety and cyber-secure connectivity.
ABB XVC517AE10 3BHB004744R0010
Technical Specifications
| Parameter Name | Parameter Value |
| Product Model | XVC517AE10 3BHB004744R0010 |
| Manufacturer | ABB |
| Product Type | Redundant Ethernet Communication Module |
| Ethernet Ports | 2 × Gigabit RJ45 (auto-sensing, with M12 optional) |
| Protocols | PROFINET IRT Class C, Modbus TCP/IP, OPC UA, IEC 61850 |
| Data Transfer Rate | 1 Gbps (full duplex) |
| Redundancy | HSR (High-availability Seamless Redundancy) |
| Failover Time | < 5> |
| Power Supply | 24 VDC (18–32 V range) |
| Power Consumption | 6.5 W (typical) |
| Operating Temperature | -40°C to +70°C (-40°F to +158°F) |
| Certifications | SIL 3 (IEC 61508), UL Class I Div 2, CE, RoHS |
| Mounting | DIN rail or direct backplate |
| Dimensions | 118 mm × 129 mm × 117 mm (H×W×D) |
Main Features and Advantages
Deterministic PROFINET IRT: The ABB XVC517AE10 achieves microsecond-level synchronization precision for motion control and time-critical processes. Its hardware-based PROFINET IRT support enables jitter-free communication in robotics, turbine control, and high-speed manufacturing lines.
Cyber-secure architecture: Integrated firewall, VLAN segmentation, and MAC address filtering protect against unauthorized access. Firmware supports encrypted TLS 1.3 connections and automated security patch management via ABB’s Control Software Manager.
Zero-downtime redundancy: Dual independent Ethernet controllers with HSR protocol eliminate single points of failure. If a cable or switch fails, the ABB XVC517AE10 3BHB004744R0010 switches paths without data loss—critical for safety shutdown systems.
Simplified diagnostics: LED status indicators per port (link/activity/fault) enable rapid troubleshooting. Module health metrics (temperature, packet error rate) are accessible through ABB’s Automation Builder or 800xA Asset Monitor. Hot-swap capability allows replacement during operation, minimizing plant downtime.
Application Field
The ABB XVC517AE10 dominates applications requiring fault-tolerant networking across heavy industries:
Power Generation: Connects turbine governors, excitation systems, and protection relays in coal/gas plants for grid stability. Supports IEEE 1588 time synchronization for phasor measurement units (PMUs).
Oil & Gas: Implements safety instrumented systems (SIS) for offshore platforms, with PROFINET IRT enabling sub-millisecond valve control in emergency shutdown scenarios.
Water/Wastewater: Integrates pumping stations, SCADA systems, and chemical dosing units across distributed plants using OPC UA for unified data modeling.
Manufacturing: Synchronizes robotic cells, CNC machines, and conveyor systems in automotive production, leveraging deterministic cycle times <1ms>
Mining: Operates in vibration-intensive environments for conveyor belt safety monitoring and ventilation control, with -40°C cold-start capability.
Related Products
ABB PM865 Processor: Main CPU module for AC 800M controllers (executes logic using XVC517AE10 data).
ABB TP830 Baseplate: Provides backplane connectivity for XVC517AE10 in redundant configurations.
ABB CI871 PROFIBUS Interface: Extends legacy device integration.
ABB SD822 Power Supply: 24VDC source for AC 800M racks.
ABB XU008 USB Module: Local engineering port for XVC517AE10 configuration.
ABB CEX-B01 Extension Unit: Expands I/O capacity for large-scale systems.
ABB 3BSE018105R1 Fiber Converter: Enables long-distance fiber-optic links for XVC517AE10.
ABB XVC517AE10 3BHB004744R0010
Installation and Maintenance
Pre-installation preparation: Verify firmware compatibility with AC 800M controller (min. version 6.1.1). Configure IP addresses/subnets in Automation Builder before mounting. Use CAT6A shielded Ethernet cables with grounded drain wires. For the ABB XVC517AE10 3BHB004744R0010, reserve adjacent slots for redundancy modules if required.
Maintenance recommendations: Monitor switch port statistics (CRC errors, collisions) quarterly. Update firmware during planned shutdowns using ABB’s Control Software Manager. Replace air filters annually in dusty environments. For module extraction, de-energize the rack or use hot-swap procedures (requires redundant power). Validate HSR failover annually by disconnecting primary Ethernet links.
