The HYBRICON PCI354-1022-38-02088-019 is a ruggedized PCI expansion card engineered for mission-critical embedded systems in industrial automation, defense, and transportation. Designed to withstand extreme environments, this module extends PCI-based connectivity in shock/vibration-prone installations like mobile machinery or unmanned systems. The PCI354-1022-38-02088-019 integrates specialized I/O interfaces (customizable per suffix codes) while maintaining MIL-STD-810G compliance for mechanical stress and MIL-STD-461F for EMI resilience. Its conduction-cooled design eliminates fans, enabling operation in dust-laden or explosive atmospheres (ATEX Zone 2). With support for extended temperature ranges (-40°C to +85°C) and 24/7 reliability, this card serves as a modular backbone for legacy system upgrades in harsh field applications.
HYBRICON PCI354-1022-38-02088-019
Technical Specifications
| Parameter Name | Parameter Value |
| Product Model | PCI354-1022-38-02088-019 |
| Manufacturer | HYBRICON |
| Product Type | Rugged PCI Expansion Card |
| Host Interface | PCI 32-bit/33 MHz |
| Custom Interfaces | 2x RS-422/485 (Isolated), 4x Digital I/O, 1x CAN 2.0B |
| Isolation Voltage | 2,500 VDC (Signal-to-Host) |
| Operating Temperature | -40°C to +85°C |
| Shock/Vibration | 50g @ 11ms (MIL-STD-810G), 5g @ 5–500 Hz |
| Power Consumption | 3.3V @ 1.2A (Max) |
| EMC Compliance | MIL-STD-461F, EN 61000-6-2/4 |
| Humidity Range | 5–95% non-condensing |
| Conformal Coating | IPC-CC-830B (Optional) |
| Dimensions | 175 x 106 mm (L x W) |
Main Features and Advantages
Extreme environment resilience: Aluminum cold-plate construction dissipates heat without airflow, critical in sealed enclosures. The HYBRICON PCI354-1022-38-02088-019’s solder-in components and strain-relief connectors survive 15g vibration in mining vehicles or drilling rigs.
Interface flexibility: “38-02088-019” suffix denotes pre-configured isolated serial/CAN ports with surge protection (±40V continuous). Digital I/O channels feature programmable sink/source modes (up to 60V/1A). Onboard EEPROM stores calibration data, enabling hot-swap replacement.
Legacy system integration: Maintains timing-critical PCI bus cycles under electromagnetic interference. Gold-plated edge connectors ensure 10,000+ insertion cycles. Custom firmware support via HYBRICON SDK.
Application Field
The PCI354-1022-38-02088-019 enables robust control in mobile/harsh environments:
Defense: Weapon system data acquisition in armored vehicles (MIL-STD-1275 power transients).
Energy: Drilling rig instrumentation surviving IEC 60068-2-6 vibration profiles.
Rail: Train control retrofits with EN 50155 compliance (-40°C cold-start).
Industrial: Robotics CAN bus expansion in foundries with molten metal splash.
HYBRICON PCI354-1022-38-02088-019
Related Products
PCI354-1021-xx: Analog I/O variant (16-bit ADC/DAC).
PCIe354-2105-xx: PCI Express rugged card with GigE Vision.
HYBRICON CPCI-3660: CompactPCI conduction-cooled SBC.
PCI354-EMC-KIT: EMI shielding kit for FCC Part 15 compliance.
HY-RS485-ISO: Isolated RS-485 daughterboard for custom configurations.
