MS-NAE5510-1 Network Automation Engine, supporting up to 100 devices, powerful functionality, and high cost-effectiveness!

The JOHNSON CONTROLS MS-NAE5510-1 is a Network Automation Engine (NAE) within Johnson Controls’ Metasys® building management system, serving as the supervisory controller for enterprise-scale HVAC, lighting, and security integration. This advanced field controller leverages the Niagara Framework® to unify multi-vendor protocols—including BACnet, LON, Modbus, and SNMP—into a single IP-native management platform. Engineered for large commercial and institutional facilities, the JOHNSON CONTROLS MS-NAE5510-1 provides centralized monitoring, data logging, and alarm management for up to 100,000 points while enabling secure remote access via embedded web servers. Its dual-core processor architecture ensures real-time processing of complex control sequences across building subsystems, with native cybersecurity features meeting NIST SP 800-53 standards.

Get a Quote
Manufacturer:
Our extensive catalogue, is available now for dispatch to the worldwide.
  • Email: sales@slxytech.com
  • WhatsApp / Wechat：8617062388866
  • Phone：+86 17062388866

Description

The JOHNSON CONTROLS MS-NAE5510-1 is a Network Automation Engine (NAE) within Johnson Controls’ Metasys® building management system, serving as the supervisory controller for enterprise-scale HVAC, lighting, and security integration. This advanced field controller leverages the Niagara Framework® to unify multi-vendor protocols—including BACnet, LON, Modbus, and SNMP—into a single IP-native management platform. Engineered for large commercial and institutional facilities, the JOHNSON CONTROLS MS-NAE5510-1 provides centralized monitoring, data logging, and alarm management for up to 100,000 points while enabling secure remote access via embedded web servers. Its dual-core processor architecture ensures real-time processing of complex control sequences across building subsystems, with native cybersecurity features meeting NIST SP 800-53 standards.

The JOHNSON CONTROLS MS-NAE5510-1 simplifies large-scale deployments through plug-and-play integration with Johnson Controls’ FX/Supervisory Controllers and third-party devices. Its 512 MB flash memory supports extensive trend logging, while the embedded SQLite database enables local analytics without server dependency. For facilities requiring high availability, the device offers redundant power inputs and automated failover to peer engines. The JOHNSON CONTROLS MS-NAE5510-1 represents the cornerstone of intelligent building infrastructure, transforming raw data into actionable insights through Metasys UI and third-party BI tools.

JOHNSON MS-NAE5510-1

JOHNSON MS-NAE5510-1

Technical Specifications

Parameter Name Parameter Value
Product Model JOHNSON CONTROLS MS-NAE5510-1
Manufacturer Johnson Controls
Product Type Network Automation Engine
Processor Dual-core 800 MHz ARM Cortex-A9
Memory 512 MB Flash, 512 MB RAM
Point Capacity 100,000 objects
Network Interfaces 2x 10/100 Ethernet (RJ45), RS-485
Supported Protocols BACnet IP/MS/TP, LON, Modbus RTU/TCP, SNMP, HTTP/HTTPS
Operating Voltage 24 VAC/VDC ±10% (Redundant Inputs)
Power Consumption 15 W (typical)
Operating Temperature -30°C to 60°C
Humidity Range 10–90% non-condensing
Enclosure Rating IP20 (DIN-rail mount)
Dimensions 180 x 110 x 65 mm
Certifications UL 916, EN 60730, FCC Part 15

Main Features and Advantages

Multi-Protocol Integration: The JOHNSON CONTROLS MS-NAE5510-1 natively translates between 15+ building automation protocols, eliminating gateways in mixed-system environments. BACnet Secure Connect (BACnet/SC) support provides encrypted communications for critical infrastructure.

Cybersecurity Hardening: Features include role-based access control (RBAC), TLS 1.2 encryption, automated certificate management, and NIST-compliant password policies. Built-in intrusion detection logs unauthorized configuration changes.

High-Performance Analytics: Onboard JACE® Virtual Machine executes Niagara AX/NG workflows locally, processing energy analytics and fault detection algorithms without cloud dependency. Stores 1+ year of 15-minute interval data.

Scalable Architecture: Modular expansion slots support I/O modules (e.g., MS-FEC2610) for direct field device connectivity. Redundancy protocols synchronize runtime databases with peer NAEs within 500 ms during failover events.

Application Field

The JOHNSON CONTROLS MS-NAE5510-1 dominates complex building automation scenarios requiring interoperability and cybersecurity. In hospitals, it unifies HVAC pressure control, surgical suite monitoring, and medical gas alarms via BACnet integration while maintaining HIPAA-compliant data isolation. University campuses deploy it to centralize 100+ buildings, correlating energy use with class schedules via LON-based lighting systems.

Data centers rely on the JOHNSON CONTROLS MS-NAE5510-1 for ASHRAE-compliant thermal management, using Modbus TCP to interface with CRAC units and SNMP to monitor UPS load profiles. Retail chains utilize its distributed architecture for regional rollups of refrigeration system diagnostics. Critical infrastructure applications include airport terminal control, where it processes baggage handling system alerts alongside perimeter security triggers. The JOHNSON CONTROLS MS-NAE5510-1 also anchors smart city projects, aggregating municipal building data through RESTful APIs.

JOHNSON MS-NAE5510-1

JOHNSON MS-NAE5510-1

Related Products



MS-NAE5520-1: Higher-tier NAE with 300,000 point capacity and expanded I/O slots.



MS-FEC2610: Field equipment controller for extending I/O to VAV boxes and sensors.



MS-VMA1610-0: BACnet VAV controller for terminal unit management.



MS-TEC3000-1: Zone controller for heat pump/split system integration.



SED2-VRP101: Variable speed drive controlled by the MS-NAE5510-1 via BACnet MS/TP.



M5-MPC: Metasys® compact controller for localized equipment sequences.



M-UIE: Universal input expansion module for analog/digital points.
