The ABB 5SHY3545L0005 represents the evolution of ABB’s medium-voltage power semiconductor technology, delivering enhanced performance for demanding industrial applications. This 4.5kV press-pack IGCT (Integrated Gate-Commutated Thyristor) stack features a 3,800A continuous current rating with exceptional 80kA surge withstand capability, engineered specifically for ACS 6000 and ACS 6080 drive platforms. Incorporating next-generation silicon-carbide hybrid clamping technology, the 5SHY3545L0005 achieves 18% lower switching losses compared to previous iterations while maintaining robust press-pack reliability. The advanced copper-tungsten electrode design enables double-sided phase-change cooling compatibility, supporting thermal densities up to 180 W/cm² for ultra-compact drive designs.
Optimized for multi-level ANPC (Active Neutral Point Clamped) converters, the ABB 5SHY3545L0005 delivers industry-leading efficiency with<3>
ABB 5SHY3545L0005
Technical Specifications
| Parameter Name | Parameter Value |
| Product Model | 5SHY3545L0005 |
| Manufacturer | ABB |
| Product Type | Press-Pack IGCT Power Stack |
| Blocking Voltage | 4.5 kV (Asymmetric) |
| Nominal Current | 3,800 A RMS |
| Max Surge Current | 80 kA (1 ms half-sine) |
| Switching Frequency | 800 Hz (Maximum) |
| Turn-off Time | <3><!--3--> |
| Thermal Resistance | 0.010 K/W (Junction-to-coolant) |
| Cooling Method | Phase-change or Direct Liquid |
| Operating Temperature | -40°C to +150°C (Junction) |
| Mounting Pressure | 42 kN ±3% |
| Isolation Voltage | 15 kV AC (1 min) |
| Short-Circuit Withstand | 18 μs |
| Weight | 9.8 kg |
| Dimensions | 218 × 150 × 58 mm (W × H × D) |
| Design Life | >250,000 power cycles |
Main Features and Advantages
Hybrid SiC Technology: Integrated silicon-carbide clamping diodes reduce reverse recovery losses by 35% versus silicon counterparts, enabling higher switching frequencies and improved system efficiency.
Intelligent Thermal Management: Four embedded fiber-optic sensors provide real-time thermal mapping, allowing adaptive switching control through gate driver communication to prevent hotspot formation.
Enhanced Ruggedness: Asymmetric pressure distribution system maintains uniform contact force during thermal cycling. Titanium-reinforced housing withstands IEC 60068-2-6 vibration (10g @ 10-2000Hz) and 100g mechanical shock.
Maintenance Optimization: Tool-less quick-disconnect terminals enable stack replacement in<8>
Cloud-Connected Diagnostics: ABB Ability™ embedded interface provides predictive health analytics for:
Switching degradation trends
Thermal interface resistance
Mechanical stress accumulation
Coolant contamination levels
Application Field
The ABB 5SHY3545L0005 powers next-generation industrial and energy systems:
Heavy Process Industry:
30MW+ reversing plate mills
Direct reduction iron (DRI) furnace power systems
Gigawatt-scale carbon capture compressor trains
Renewable Integration:
1500V DC solar farm central inverters (>15MW)
Battery energy storage system (BESS) converters
Hydrogen electrolyzer power supplies
Marine & Offshore:
Dynamic positioning thrusters for drilling rigs
LNG carrier cargo compressor drives
Shore connection systems with 6.6kV direct conversion
Grid Infrastructure:
Modular multilevel converters for HVDC interconnects
Synchronous condenser replacements
Black start systems for critical generation facilities
ABB 5SHY3545L0005
Related Products
3BHE039325R0101: Advanced gate driver for 5SHY3545L0005
5SXE20-0450: Phase-change cooling unit (25kW capacity)
5SHY55L4512: 5.5kV/4.2kA stack for higher voltage applications
5SGF45R4505: 4500V ultra-low-inductance snubber capacitor
5STP35Q4500: Silicon carbide freewheeling diode assembly
5SNA3200G450400: DC-link capacitor bank (11,000μF)
5SHX3545L0007: Next-generation 4.5kV/4.5kA evolution
