The Woodward EASYGEN-3500-5 P2, with part number 8440-2145, is a sophisticated, microprocessor-based generator set controller designed for the automatic control, monitoring, and protection of single or multiple diesel or gas-powered generator sets. Part of Woodward’s renowned EASYGEN® series, this advanced control unit is engineered to provide seamless integration into both standalone power systems and complex parallel operation environments. The “P2” designation typically indicates a specific hardware revision or configuration variant optimized for enhanced performance and connectivity.
The EASYGEN-3500-5 excels in applications requiring high reliability and automation, such as standby power for hospitals, data centers, industrial facilities, and prime power for remote off-grid operations. It supports fully automatic start/stop sequences based on external commands (e.g., from a building management system or power failure), comprehensive engine and alternator protection, load management, and synchronization functions. With its robust design and extensive feature set, the EASYGEN-3500-5 P2 ensures safe, efficient, and uninterrupted power generation across diverse operational scenarios.
EASYGEN-3500-5 P2 8440-2145 WOODWARD
Key Features and Capabilities
- Automatic Start/Stop Control: Initiates generator startup upon loss of mains (standby mode) or according to a programmable schedule (prime power mode). Automatically transfers load and performs cooldown shutdown.
- Mains and Generator Protection: Monitors voltage, frequency, and phase sequence for both utility supply and generator output. Provides configurable over/under voltage, over/under frequency, phase reversal, and loss of mains detection.
- Synchronization & Load Sharing: Supports automatic synchronization to the utility grid or to other generators in parallel operation. Enables active and reactive load sharing in multi-unit installations.
- Advanced Monitoring: Continuously tracks critical parameters including engine speed (RPM), oil pressure, coolant temperature, battery voltage, kW, kVA, kVAR, PF, current, and cumulative run hours.
- Digital I/O Flexibility: Equipped with multiple programmable digital inputs and relay outputs for interfacing with sensors, breakers, alarms, and auxiliary equipment.
- Communication Interfaces: Features integrated Ethernet (Modbus TCP), RS-485 (Modbus RTU), and CAN bus (J1939) for seamless integration into SCADA systems, Building Management Systems (BMS), and remote monitoring platforms.
- User Interface: High-resolution color touchscreen display with intuitive menu navigation, real-time trending, event logs, alarm history, and diagnostic tools.
- Configurable Logic: Supports user-defined logic functions, timers, and interlocks via built-in software tools for custom application requirements.
- Cyber Security: Includes modern security features such as password protection, role-based access control, and secure communication protocols (depending on firmware version).
- Compliance & Certification: Designed to meet international standards including ISO 8528, IEC 60255, UL 2200, and CSA C22.2 No. 107.1.
Technical Specifications
| Parameter | Specification |
| Model | EASYGEN-3500-5 P2 |
| Part Number | 8440-2145 |
| Manufacturer | Woodward |
| Application | Generator Set Controller |
| Display | Color TFT touchscreen (typically 4.3″ or 5.7″) |
| Voltage Sensing | 3-phase or single-phase (adjustable ranges up to 690 V AC) |
| Frequency Range | 50/60 Hz (±10%) |
| Inputs | Multiple analog (0–10 V, 4–20 mA) and digital inputs |
| Outputs | Relay outputs (for starter, fuel, alarms, breaker control), analog outputs (optional) |
| Communication Ports | Ethernet (Modbus TCP), RS-485 (Modbus RTU), CAN J1939 |
| Power Supply | 12–32 VDC (nominal 24 VDC), wide operating range with reverse polarity protection |
| Protection Class | IP65 (front panel), NEMA 4X (when properly mounted) |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Certifications | CE, UKCA, RoHS, UL Listed (to UL 2200), CSA |
| Mounting | Panel mount (standard cutout) |
Application Field
The Woodward EASYGEN-3500-5 P2 (8440-2145) is ideal for:
- Standby Power Systems: Automatic backup for hospitals, telecom sites, airports, and commercial buildings.
- Prime Power Applications: Continuous power generation in mining, construction, and remote communities.
- Parallel Operation: Synchronizing multiple gensets or synchronizing to the grid in cogeneration and peak shaving systems.
- Marine & Offshore: Auxiliary power control on vessels and offshore platforms.
- Renewable Integration: Hybrid systems combining generators with solar or wind power.
- Industrial Plants: Ensuring uninterrupted operation during grid outages.
Its ability to manage complex control sequences, communicate with higher-level systems, and support redundancy makes it suitable for mission-critical power infrastructure.
EASYGEN-3500-5 P2 8440-2145 WOODWARD
Related Products and Accessories
- EASYLAN Module: Adds LAN connectivity and web server functionality for remote access.
- EASYSync Module: Enhances synchronization and load sharing capabilities in multi-genset plants.
- EASYConnect Software: PC-based tool for configuration, monitoring, and firmware updates.
- EASY Manager Cloud Platform: Enables cloud-based remote monitoring and fleet management.
- Current Transformers (CTs): Required for accurate current and power measurement.
- Voltage Sensing Transformers (VTs): For high-voltage applications.
- Circuit Breaker Interfaces: Motor operators and auxiliary contacts for auto-transfer schemes.
- Battery Chargers & Supervision Modules: To ensure reliable starting capability.
- Other EASYGEN Models:
- EASYGEN-1500: Basic single genset control.
- EASYGEN-2500: Advanced control with Modbus.
- EASYGEN-4000: High-end controller for complex paralleling and energy management.
